Singlemode 0dB Male SC/UPC to Female SC/APC Optical Fiber Adapter Connector
Singlemode 0dB Male SC/UPC to Female SC/APC Optical Fiber Adapter Connector
Introduce:
- Fixed Attenuator is a precise passive component which provides different fixed attenuation value to meet optical fiber projects’ demands.
- Our fixed attenuator is made of high precision adapter and features high attenuation precision and good performance.
- SC fiber optic attenuator includes SC single mode female to female fiber optic attenuator from 0dB to 30dB.
- This type of fiber optic attenuator adapter can do Male SC UPC to Female SC APC or Male SC APC to Female SC UPC.
- Use to connect SC fiber optic pigtail or patch cables to reduce the power of signal at a certain attenuation.
- SC fiber optic attenuator is a passive device used to reduce the amplitude of a light signal without significantly changing the wave form itself.
- This is often a requirement in Dense Wave Division Multiplexing(DWDM) and Erbium Doped Fiber Amplifier (EDFA) applications where the receiver can’t accept the signal generated from a high-power light source.
- Optic fiber Communication Systems
- Optical Fiber Sensor
- Optical Fiber Test Equipment
- Optic fiber CATV
- Dense Wave Division Multiplexers (DWDM)
- Overpowered fiber optic systems
- Fiber optic communication systems.
- High-power light source durability.
- Wavelength independence.
- Attenuation levels ranging from 1dB to 30dB, with standard and premium tolerances, plus custom configurations.
- Effectively avoiding damage.
- Ceramic core,telecom grade standard setting.
- Metal texture.
| Parameter | Value | Unit |
| Operating Wavelength | 1310/1550 | nm |
| Tolerance for 1~5 dB Attenuation | ± 0.5 | dB |
| Tolerance for 6~30 dB Attenuation | ± 10 | % |
| Return Loss | > 65 | dB |
| Operating Temperature | -40 to +80 | C |
| Polarization Dependent Loss | ≤ 0.1 | dB |
| Mating Durability | ≥ 1000 | cycle |
| Transfer Mode | SM | |
| Connector Gender | Fiexd Male to Female | |
Features:
- High precision.
- Good stability.
- Small size and bulk.
- Easy to operate.
- Data Center Infrastructure
- Storage Area Network and Fiber Channel
- Based on IEC/Telcordia Bell GR-326-Core Tested
- High-power light source durability
- Wavelength independence
- Attenuation levels ranging from 1dB to 25dB
- 1310nm, 1550nm and 1310/1550nm dual wave lengths
