12 Cores Min Capacity Fiber Optic Junction Box Horizontal Type For PLC Splitter
Price:
Negotiable
MOQ:
Negotiation
Delivery Time:
5~14 working days
Brand:
KCO, Kocent Optec Limited
Product Description
KCO-02A-16 Horizontal 1 In 4 Out Fiber Optic Splice Enclosure Junction Box
For PLC Splitter 1*16 2*16
Quick detail:
- Part number:KCO-02A-16
- Name:Splitter Fiber Optic Splice Closure Box
- Size:430*130mm
- Packing:1pc/small carton/ 45*21*19cm/ 3.0kg
- Cable entry port:1 ports
- Cable out port:4 ports
- Capacity of fibers:96 cores
- Splice tray number:max. 4 trays
- Can Install:1x2 Splitter, 1x4 Splitter, 1x8 Splitter, 1x12 Splitter, 1x16 Splitter.
- Material:ABS / PP Plastic
- Packing:6pcs/ carton box
- Packing size:47*47*62cm
- Cable Diameter:7.0-22.0mm
- Water-proof grade:IP67
- Working temperature:-30℃ to 60℃
- Life time:>25 years
Main accessories and special tools
| No. | Name of accessories | Quantity | Usage | Remarks |
|---|---|---|---|---|
| 1 | Heat shrinkable protective sleeve | Protecting fiber splices | Configuration as per capacity | |
| 2 | Nylon tie | Fixing fiber with protective coat | Configuration as per capacity | |
| 3 | Heat shrinkable fixing sleeve (single) | Fixing and sealing single fiber cable | Configuration as per requirement | |
| 4 | Heat shrinkable fixing sleeve (mass) | Fixing and sealing mass of fiber cable | Configuration as per requirement | |
| 5 | Branching clip | Branching fiber cables | Configuration as per requirement | |
| 6 | Earthing wire | 1 piece | Putting through between earthing devices | |
| 7 | Desiccant | 1 bag | Put into FOSC before sealing for desiccating air | |
| 8 | Labeling paper | 1 piece | Labeling fibers | |
| 9 | Special wrench | 1 piece | Tightening nut of reinforced core | |
| 10 | Metal hoop | 1 set | For wall mounting and pole hugging | |
| 11 | Buffer tube | customer decide | Hitched to fibers and fixed with FOST, managing buffer. | Configuration as per requirement |
| 12 | Aluminum-foil paper | 1 piece | Protect the bottom of FOSC |
Main components
| No. | Name of components | Quantity | Usage | Remarks |
|---|---|---|---|---|
| 1 | FOSC cover | 1 piece | Protecting fiber cable splices in whole | |
| 2 | Fiber optic splice tray (FOST) | Max. 6 trays (bunchy) Max. 4 trays (ribbon) | Fixing heat shrinkable protective sleeve and holding fibers | Suitable for: Bunchy:12,24(cores); Ribbon:6 (pieces) |
| 3 | Fiber holding tray | 1 pcs | Holding fibers with protective coat | |
| 4 | Base | 1set | Fixing internal and external structure | |
| 5 | Plastic hoop | 1 set | Fixing between FOSC cover and base | |
| 6 | Seal fitting | 1 piece | Sealing between FOSC cover and base | |
| 7 | Pressure testing valve | 1 set | After inject air, it is used for pressure testing and sealing testing | Configuration as per requirement |
| 8 | Earthing deriving device | 1 set | Deriving metal parts of fiber cables in FOSC for earthing connection | Configuration as per requirement |
OEM/ODM Service:
If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.
Packing:
According to Stardard Export Packing.
Carton box, wooden box, wooden pallet.
Shipping:
- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- By sea
