4 Way 600-6000MHz 50W IP65 RF Power Splitter Hybrid Coupler
Outdoor Wilkinson Model 600-6000MHz 50W IP65 -153dBc 4 Way RF Power Splitter
Splitter Specification:
| Model No. | GW-MWPS-6060-02-41F-153 | GW-MWPS-6060-03-41F-153 | GW-MWPS-6060-04-41F-153 |
| Freq(MHz) | 600-6000 | ||
| Split Loss(dB) | 3.0 | 4.8 | 6.0 |
| Insertion Loss(dB) | ≤1.0 | ≤1.2 | ≤1.5 |
| Isolation(dB) | ≤18 | ≤16 | ≤16 |
| VSWR | ≤1.45 | ≤1.50 | ≤1.50 |
| PIM (dBc) | ≤-153dBc@2*43dBm (698-2700) | ||
| Power(W) | 50(average) | ||
| Impedance | 50 ohm | ||
| Connector | 4.3/10-female | ||
| Color | Silver-plated | ||
| Temp(deg) | -30~+70 | ||
| Application | Indoor or Outdoor | ||
Product Description
Power dividers (also power splitters and, when used in reverse, power combiners) and directional couplers are used mostly in the field of radio technology. An essential feature of directional couplers is that they only couple power flowing in one direction. Power entering the output port is coupled to the isolated port but not to the coupled port. A directional coupler designed to split power equally between two ports is called a hybrid coupler.
4-Way RF Power Divider, Combiner, Splitter has 50 Ohms impedance. It has Type N female connectors. This 4-way wide-band divider, combiner, and splitter cover 600 MHz through 6000 MHz frequencies.
