WCDMA AC240V Cell Phone Signal Repeater 2600MHz 33dBm 2W Tri Band
Price:
Negotiable
MOQ:
1
Delivery Time:
15work days
Brand:
Greetwin
Product Description
Greetwin High Power Professional 2W Tri-Band 1800 2100 2600 MHz 33dBm Signal Repeater
|
Frequency range
|
Uplink (UL) |
Downlink (DL)
|
|
| DCS 1800 MHz | 1710MHz - 1785MHz | 1805MHz - 1880MHz | |
| WCDMA 2100 MHz | 1920MHz - 1980MHz | 2110MHz - 2170MHz | |
| LTE 2600 MHz | 2500MHz - 2570MHz | 2620MHz - 2690MHz | |
|
Bandwidth
|
25 MHz
|
25 MHz
|
|
|
Output Power
|
MU
|
-10 ± 2dBm
|
-
|
|
|
RU
|
-10dBm
|
43 ± 2dBm
|
|
Gain
|
MU + RU
|
-
|
90 ± 2dB
|
|
Ripple in band
|
≤ 6dB
|
≤ 6dB
|
|
|
VSWR
|
≤ 1.5
|
≤ 1.5
|
|
|
Max Input Power without Damage
|
-10dBm
|
10dBm
|
|
|
Inter-modulation Products
|
9KHz~1GHz
|
≤ -36dBm
|
≤ -36dBm
|
|
|
1GHz~12.75GHz
|
≤ -30dBm
|
≤ -30dBm
|
|
Spurious Emission
|
9KHz~1GHz
|
≤ -36dBm
|
≤ -36dBm
|
|
|
1GHz~12.75GHz
|
≤ -30dBm
|
≤ -30dBm
|
|
EVM
|
≤ 12.5%
|
≤ 12.5%
|
|
|
ATT (Gain Adjustable Range) (RU)
|
0 ~ 30dB
|
0 ~ 30dB
|
|
|
ALC (AGC), Auto Gain (Level) Control Range
|
≥ 20dB
|
≥ 20dB
|
|
|
ALC (AGC) active @ 10dB, output error
|
≤ 2dB
|
≤ 2dB
|
|
|
Repeater Setting with Control Key
|
Yes
|
||
|
Local & Remote Control
|
Local
|
RJ-45
|
|
|
Remote
|
Built in Wireless (SMS or data) Modem
|
||
|
Optical Receiver Sensitivity
|
≥ -20dBm
|
||
|
Transmission Distance
|
≥ 20KM
|
||
|
Power Supply
|
|
AC 100 ~ 240V
|
|
|
Power Consumption
|
MU
|
≤ 50w
|
|
|
RU
|
≤ 400w
|
||
|
RF Connector
|
N-Female (MU & RU)
|
||
|
Protection Grade
|
MU
|
IP30
|
|
|
RU
|
IP65
|
||
|
Grounding
|
DC to Ground (MU & RU)
|
||
|
Relative Humidity
|
5% ~ 95%
|
||
|
Operating Temperature
|
-20ºC ~ +55ºC
|
||
|
Size
|
MU
|
485*305*44mm
|
|
|
|
RU
|
450*350*190mm
|
|
|
Weight
|
MU
|
< 6kg
|
|
|
|
RU
|
< 25kg
|
|
