CNC Milling Machine ME-850/ME-1600 Series(cast aluminium.high precision)

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Product Description

Model No.		ME-850
Capacity	X axis travel/mm	850
	Y axis travel/mm	500
	Z axis travel/mm	550
	Spindle nose to table surface/mm	150-700
	Spindle nose to column surface/mm	550
Worktable	Table Size(L*W)	1000x500
	Max Load on the table/kg	500
	T-Slot Size/mm	18x5x100
Spindle	Spindle speed/rpm	60-8000
	Spindle taper/spindle shank	7/24Taper/BT40
	Spindle bearing internal diameter	70
Feed rates	Rapid traverse of X,Y Axis m/min	24/24/24
	Max. cutting feed rate m/min	10

A.T.C	TOol storage capacity/pcs	24
	Maxi Tool diameter(adjacent tool)/mm	150 (80)
	Max tool length/mm	300
	Tool Change Time (T-T/C-C)/sec	2.5
Motor	Spindle Motor	7.5
Motor	X/Y/Z axis servo motor/kw	1.8/1.8/2.5
Precision	Positioning accuracy/mm	±0.01
Precision	Repeated Positioning accuracy/mm	±0.005
Machine dimension	Height of Machine /mm	2330
	Floor Area(width X depth)/mm	2730x2200
	Machine weight/kg	5000
	Power Requirements/kva	20
	Milling machine cOntroller	Siemens 808D
