SM110NC automatic Full oil pressure hydraulic tube end forming machines
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Product introduction:
Full oil pressure automatic pipe/tube end forming machine, shrink, magnifying, crease.
Detailed description:
1.Applicable material of the machine: carbon steel, stainless steel, aluminum, alloy, copper, brass etc.
2.Microcomputer controlling; Hydraulic driving.
3.Manual and semi-automatic operations are available.
4.English or Chinese subtitles; man-machine conversion operation, easy.
5.Adopting linear slider rail, stable propulsion.
6.High accuracy and efficiency.
7. the design of the tooling is depending on customers' requirements.
Technical Parameter:
| Model | SM110NC |
| Max tube(mm) | 110mmX 2mm wall thickness |
| Max processing length(mm) | 160mm |
| Oil pressure(Mpa) | 14mpa |
| Working speed | 140mm in 6-7sec |
| Power(KW) | 7.5kw |
Applications:
It is the ideal tube end forming processing equipment which is widely used in the processing of pipe parts connection, automobile oil tube, air hose, water pipe, air conditioning pipe and other joint part. Processing shapes include: convex, concave, flat, square, Extension oblique, V-shaped, opening elbow, flat elbow, etc. Which are in accordance with specific manufacturing mold.
Machine feature:
1.NC Control Unit: Easy Operation and Maintenance
2.Removable foot pedal, high security with auto, E-stop, continuing operation.
3.Whatever contract pipe, flare pipe and crease pipe or combination operation, it is an ideal machine for pipe end forming.
4.It is simple for changing the tooling so much easy help for manufacture.
5.Standard outfit: tooling, tool kit, manual.
6.Special outfit: special forming die.
It is the ideal tube end forming processing equipment which is widely used in the processing of pipe parts connection, automobile oil tube, air hose, water pipe, air conditioning pipe and other joint part. Processing shapes include: convex, concave, flat, square, Extension oblique, V-shaped, opening elbow, flat elbow, etc. Which are in accordance with specific manufacturing mold.
Machine feature:
1.NC Control Unit: Easy Operation and Maintenance
2.Removable foot pedal, high security with auto, E-stop, continuing operation.
3.Whatever contract pipe, flare pipe and crease pipe or combination operation, it is an ideal machine for pipe end forming.
4.It is simple for changing the tooling so much easy help for manufacture.
5.Standard outfit: tooling, tool kit, manual.
6.Special outfit: special forming die.
