SUS304 Jet Submersible Mixer Pump 415V Submersible Mixers Sewage
Submersible mixer cast iron SUS304 Jet Mixer (cast iron,Stainless Steel, leak sensor)
Detailed Product Description
2. High efficiency, self-cleaning function
3. High efficiency, self-cleaning function
QJBsubmersible mixer as a water treatment process is one of the key equipment in the water treatment process, the biochemical processes can be realized in solid-liquid two-phase flow and homogeneous solid-liquid-gas flow, the flow of process requirements. It consists of submersible motor, impeller and mounting system, etc.
Applications
Stirring to create a flow for the month, to improve water quality, increase oxygen content in water, effectively prevent the deposition of suspended solids
Conditions of Use
In order to ensure the normal to make diving mixer, please select the correct working environment and operating mode.
Maximum medium temperature does not exceed 40 degrees; and PH range: 5-9;
Medium density not exceeding 1150Kg / m 'diving deeper than 10m.
Mixer must be fully submerged underwater diving work, not flammable and corrosive and high temperature environments
QJB5/12 material on SS 304
submersible mixer QJB4/6 material on cast iron
Specification
| Model | Motor power (kw) |
Rated current (A) |
rpm of impeller(r/min) |
Diameter of impeller(mm) |
Thrust (N) |
Weight (KG) |
| QJB0.85/6-260/740-/C/S | 0.85 | 3.2 | 740 | 260 | 163 | 55/65 |
| QJB1.5/260/960/C/S | 1.5 | 4 | 960 | 260 | 290 | 55/65 |
| QJB2.2/8-320/740/C/S | 2.2 | 5.9 | 740 | 320 | 582 | 88/93 |
| QJB4/6-320/960/C/S | 4 | 10.3 | 960 | 320 | 609 | 88/93 |
| QJB1.5/6-400/740-/C/S | 1.5 | 5.2 | 740 | 400 | 600 | 74/82 |
| QJB2.5/6-400/740C/S | 2.5 | 7 | 740 | 400 | 800 | 74/82 |
| QJB3/6-400/740/C/S | 3 | 8.6 | 740 | 400 | 920 | 74/82 |
| QJB4/6-400/960/C/S | 4 | 10.3 | 960 | 400 | 1200 | 74/82 |
| QJB4/6-620/480/S | 4 | 14 | 480 | 620 | 1400 | 190/206 |
| QJB5/12-620/480/S | 5 | 18.2 | 480 | 620 | 1800 | 196/212 |
| QJB7.5/12-620/480/S | 7.5 | 28 | 480 | 620 | 2600 | 240/256 |
| QJB10/12620/480/S | 10 | 32 | 480 | 620 | 3300 | 250/266 |
