7" Tire Chain Drive Four Stroke Youth Racing ATV Air Cooled With Reverse
Four-stroke, air cooled, Chain drive,7”tire, front drum and rear disc, with reverse
Model:
youth racing atv110-18
Product Description:
| Engine type | 110cc,semi-auto,single cylinder, Four-stroke, air cooled, Chain drive, |
| Engine brand | Baitai |
| Displacement | 110cc |
| Cooling | Air cooled |
| Max horsepower | 5.5/8000 kw/r/min |
| Max torque | 7.2/6500 Nw/r/min |
| Bore*stroke | 52.4mm |
| Max speed | <=61 |
| Climbing ability | <=20 |
| Ignition | CDI |
| Starting system | Electric start |
| Battery | 12V4AH |
| Carburetor brand | KUNFU |
| Engine oil | 15w/40-se |
| Gear oil | 15w/40-se |
| CHASSIS ETC. | |
| Clutch | Automatic |
| Transmission | D-N-R |
| Driveline | Chain drive |
| Driving wheel | 2-Drive wheel |
| Suspension,front/rear | Front swing arm, dubble |
| Brakes,front/rear | Front drum Brake Rear Disc brake |
| Brake operation | Front hand brake and rear leg brake |
| Tires,front/rear | 16*8-7,16*8-7 |
| Fuel capacity/type | 3L |
| Weight,G.W./N.W. | 120/100KG |
| Max load | 198LBS |
| DIMENSIONS | |
| Wheelbase | 940mm |
| OA L*W*H | 1500*980*960mm |
| Height to seat | 640mm |
| Min ground clearance | 95mm |
| Carton size | 1300*760*640mm |
| Shipping info | 36pcs/20’gp,81pcs/40’gp,108pcs/40’HQ |
Applications:
1. adult use only
2. Forest road
3. Riverbed, Stream,
4 Mountain Road / Beach
5. Farm / Pleasure Ground
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or . The delivery time is about 20 days.
Our Service:
1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.
