Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
400cc,4 Stroke,with balance shaft,Water Cooled,Electric Start and Hang Pull
Model:
utility vehicle atv400-10
Product Description:
| ENGINE | |
| ENGINE TYPE | 4 Stroke,with balance shaft,Water Cooled |
| MAX.POWER(KW/rpm) | 15.2KW @ 7000rpm |
| MAX.TORQUE(NM/rpm) | 28N.M @ 5500rpm |
| CYLINDER NO. | Single Cylinder |
| BORE STROKE | 78mm × 75.2mm |
| DISPLACEMENT | 359.1ml |
| COMPRESSION RATIO | 10.5:1 |
| SPARK PLUG | DR8EA |
| STARTING | Electric Start & Hang Pull |
| IGNITION | C.D.I |
| DRIVETRAIN | |
| FINAL DRIVE SYSTEM | Shaft / 4WD & 2WD |
| TRANSMISSION | Automatic CVT with H-L-N-R |
| MAX.SPEED | 82KM/h |
| SUSPENSION/BRAKES | |
| SHOCK ABSORBER | Four-wheel independent suspension |
| The snow characteristics | Four-snow Rubble Tracks Can be choosed |
| BRAKE FRONT&REAR | Hydraulic disc brake |
| BRAKE DISTANCE | 7m @ 30km/h |
| MISC | |
| BATTERY | 12V/14AH |
| ENGINE OIL | 1.5L |
| FUEL | 90# unleaded gasoline |
| FUEL CAPACITY | 19L |
| MAX.LOAD(kgs/lbs) | 180kg |
| FRONT& REAR TIRE | 25×8-12/25×10-12/25 |
| OVERALL | 2250×1180×1230 |
| PACKAGE40HQ`(SET) | 30pcs |
| SEAT HEIGHT(mm) | 900mm |
| NET WEIGHT(kgs/lbs) | 305kgs |
Applications:
1. adult
2. Forest road
3. Riverbed, Stream
4. Mountain Road
5. Beach
6. Farm
7. Pleasure Ground
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or . The delivery time is about 20 days.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
1. All of the ATV Frame is use the 2.5mm seamless steel pipe ligt arc welding,production by our factory workeshop.reliable and stability.
2. All of the ATV engine is come from original engine factory. have not the renovation engine.
3.Each one ATV come out from factory, All must go through rigorous drive testing.To ensure the quality of each ATV.
4.We have one Professional team to do the after-sales service, Provide the solution to solve your worries on the ATV problems.
Warranty time
We supply you 12 months for warranty time, during the warranty time, we supply you free parts!!
