32HP 500cc Quad Utility Vehicels ATV With Manual Gear Shifting
Utility Vehicels ATV 32HP 500cc Quad ATV 4x4 Belt CVT Full Auto with H, L, N, R Manual gear shifting
Model:
utility vehicle atv500cc-07
Product Description:
Engine Type: 500cc Water Cooled, Four Stroke, single Cylinder, 4 Valve
Bore x Stroke: 92 x 75mm
Max Power: 24kW (32.2hp)/6300rpm
Max Torque: 40Nm/4800rpm
Compression Ratio: 10.2:1
Carburetion: CVK KE1 H1N 75NA, Single Chamber
Ignition: CDI
Starting System: Electric and Pull Start
Fuel Capacity: 10.5L
Max Speed: 76km/h
Transmission: Belt CVT Full Auto with H, L, N, R Manual gear shifting
Brakes: 4 Wheel Disk Brakes
Drive Train: 2WD/4WD adjustable by push button, rear wheels always lock, no differential, shaft drive
Suspension/front: Independent double wishbone
Suspension/rear: Independent double wishbone
Brake/front: Dual hydraulic disc, twin pistons
Brake/rear: Hydraulic disc, self-adjust packing system, shaft mounted
Tires/front: AT25 x 8-12
Tires/rear: AT25 x 10-12
Dimensions:
L x W x H: 2,050 x 1,150 x 1,450mm
Wheelbase: 1,280mm
Turning radius: 3,600mm
Ground clearance: 230mm
Container Quantity:
1x20'ft container: 10pcs
1x40'hq container: 24pcs
Applications:
Mountain Road, Beach , adult , Forest road, Riverbed, Stream , Farm and Pleasure Ground
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or . The delivery time is about 20 days.
FAQ:
| 1. | ask: | What is the minimum order quantity? | |||||||||||
| answer: | MOQ for ATV: 1pc, MOQ for spare parts: 5pcs | ||||||||||||
| 2. | ask: | What is the production and delivery time? | |||||||||||
| answer: | Delivery for ATV: 20-30 days. Delivery for spare parts: 5-15days | ||||||||||||
| 3. | ask: | Can I order a sample ? | |||||||||||
| answer: | Yes for spare parts,and need 200 USD as sample fee for ATV. | ||||||||||||
| 4. | ask: | Can we use our own shipping agent ? | |||||||||||
| answer: | Sure. | ||||||||||||
| 5. | ask: | Can we mix the 20ft container ? | |||||||||||
| answer: | Yes, you can mix no more than 4 models in a 20ft container and no more than 6 model in a 40HQ container. | ||||||||||||
| 6. | ask: | Can we use our own logo or design for sticker ? | |||||||||||
| answer: | Welcome! | ||||||||||||
| 7. | ask: | How often do you develop new models? | |||||||||||
| answer: | We regularly develop 1 new model per 3 months. | ||||||||||||
| 8. | ask: | Do your factory have Certificate? | |||||||||||
| answer: | We have CE for all of our ATV products and EEC for mostly of ATV products. | ||||||||||||
