W01-358-9031 Firestone Rolling Lobe Air Spring Bellow No.1T15M-0 Truck Air Suspension With Piston
W01-358-9031 Firestone Rolling Lobe Air Spring Bellow No.1T15M-0 Truck Air Suspension With Piston
Product Description
|
Item |
Truck Air Springs |
GUOMAT NO. |
1T9031 |
|
Warranty |
1 Year |
Material |
Rubber+Steel |
|
MOQ |
1 pc |
Package |
Carton |
|
OEM |
Firestone W01-358-9031 |
Replaces |
0550-00051 |
GUOMAT 1T9031 Air Spring Cross Reference
Firestone Bellow Number: 1T15M-0
Firestone Bellow Number: 1T15M 0
Firestone OEM Number: W01-358-9031
Firestone OEM Number: W01 358 9031
Firestone OEM Number: W013589031
Firestone OEM Number: WO1-358-9031
Firestone OEM Number: WO1 358 9031
Firestone OEM Number: WO13589031
|
Airspring Supplier |
Supplier Number |
Airspring Supplier |
Supplier Number |
|
Contitech |
91010P339 |
Goodyear |
1R12115 |
|
Goodyear |
1R12-115 |
Goodyear |
566243061 |
|
Goodyear |
566-24-3-061 |
Goodyear |
1R12350 |
|
Goodyear |
1R12-350 |
Goodyear |
566243067 |
|
Goodyear |
566-24-3-067 |
Triangle |
6360 |
|
Triangle |
8339 |
Flxible |
63792 |
|
Peerless |
55000051 |
Peerless |
0550-00051 |
|
Ridewell |
1003589031C |
Firestone Trimmed |
w013589031 |
Firestone Truck AirBags Technical Data
BEAD PLATE TOP DATA
Top Bead Plate Diameter: 9.00 in
Air Inlet: 1/4NPT
Center Distance Between Threaded Holes: 6.20 in
Distance between Threaded Hole and Air Inlet: 2.88 in
PISTON BOTTOM DATA
Diameter of Bottom Piston: 9.50 in
Number of Threaded Hole: 3
Piston Height: 3.00 in
RUBBER BELLOW
Rubber Bellow Diamater: 10.12 in
Max.Height: 12.20 in
Min.Height: 5.30 in
Contitech Assembly Number to Firestone
|
Contitech Air Spring 9 10-10 P 311 |
Firestone Rolling Lobe Airbag W013589039 |
|
Contitech Air Spring 9 10-10 P 328 |
Firestone Rolling Lobe Airbag W013589033 |
|
Contitech Air Spring 9 10-10 P 331 |
Firestone Rolling Lobe Airbag W013589077 |
|
Contitech Air Spring 9 10-10 P 339 |
Firestone Rolling Lobe Airbag W013589031 |
|
Contitech Air Spring 9 10-10 P 397 |
Firestone Rolling Lobe Airbag W013589332 |
|
Contitech Air Spring 9 10-10 P 398 |
Firestone Rolling Lobe Airbag W013589308 |
|
Contitech Air Spring 9 10-10 P 399 |
Firestone Rolling Lobe Airbag W013589029 |
|
Contitech Air Spring 9 10-10 P 400 |
Firestone Rolling Lobe Airbag W013588986 |
|
Contitech Air Spring 9 10-10 P 465 |
Firestone Rolling Lobe Airbag W013589335 |
|
Contitech Air Spring 9 10-10 P 471 |
Firestone Rolling Lobe Airbag W013589307 |
|
Contitech Air Spring 9 10-10 P 473 |
Firestone Rolling Lobe Airbag W013588963 |
|
Contitech Air Spring 9 10-10 P 480 |
Firestone Rolling Lobe Airbag W013588964 |
|
Contitech Air Spring 9 10-10 P 482 |
Firestone Rolling Lobe Airbag W013589334 |
|
Contitech Air Spring 9 10-10 P 503 |
Firestone Rolling Lobe Airbag W013588976 |
|
Contitech Air Spring 9 10-10 P 542 |
Firestone Rolling Lobe Airbag W013588961 |
The Package Picture of Truck Air Suspension Spring
