Rear Truck Air Shock Absorber 20427897 Air Suspension Spring For VOL-VO FH12 / FH16

Rear Truck Air Shock Absorber 20427897 Air Suspension Spring For VOL-VO FH12/FH16

Product Description


Technical Data
Weight: 3.429kg
Drive type: Pneumatic
Maximum length: 406mm
Minimum length: 360mm
Piston rod diameter: 14mm
The diameter of the circle where the fixed point is located: 14mm



How to Replace a VOL-VO Truck Cab Shock Absorber
Ensure the truck is parked on a flat, level surface and the engine is turned off.
Remove the retaining clip that secures the bottom stud of the shock absorber to the cab suspension crossmember. This can be done using a suitable tool, such as pliers or a clip remover tool.
Locate and remove the upper base nut that secures the top of the shock absorber to the cab. This can be done using a suitable tool, such as an impact wrench or a ratchet and socket set.
Once the upper base nut has been removed, the shock absorber can be pulled out of position and removed from the cab.
Install the new shock absorber by sliding it into position and securing the upper base nut in place using a suitable tool. Ensure the nut is tightened to the manufacturer's specifications.
Attach the bottom stud of the shock absorber to the cab suspension crossmember and secure it in place using a new retaining clip.

20427897 Truck Cab Air Shock Real Pictures
