1R13-039 Goodyear Truck Air Suspension Repair Kits 4810 NP 03 Contitech Air Spring Replacement

1R13-039 Goodyear Truck Air Suspension Repair Kits 4810 NP 03 Contitech Air Spring Replacement

Product Description

A truck suspension air spring, also known as an airbag or air suspension, is a component of a vehicle's suspension system that uses compressed air to support the weight of the vehicle and provide a smoother ride. It is typically made of a flexible and durable rubber material and is designed to replace traditional coil or leaf springs in certain applications.

Refer Numbers:

Firestone Part Number W01-358-9141

Firestone Part Number W01 358 9141

Firestone Part Number W013589141

Firestone  Bellow Number 1T19F-7

Firestone Bellow Number 1T 19F-7

Firestone Bellow Number 1T19F 7

Firestone Part Number W01-358-9121

Firestone Part Number W01 358 9121

Firestone Part Number W013589121

Firestone Bellow Number 1T19L-7

Firestone Bellow Number 1T 19L-7

Firestone Bellow Number 1T19L 7

Contitech Part Number 4810NP03

Contitech Part Number 4810 NP03

Contitech Part Number 4810 NP 03

Contitech Bellow Number 10.5-17A317

Goodyear Part Number 1R13-039

Goodyear Part Number 1R 13-039

Goodyear Part Number 1R13 039

Goodyear Flex Number 566-26-3-051

Goodyear Flex Number 566 26 3 051

Goodyear Flex Number 566263051

Goodyear  Piston Number 566-20-7-327

Goodyear Piston Number 566 20 7 327

Goodyear Piston Number 566207327

Sauer Part Number P50-733

Ridewell Part Number 1003589121C

Waston&Chalin AS-0013


GUOMAT 1T9141 Detailed Technical Parameters
Top cover diameter: 289mm
Base diameter: 260mm
Combination column of top cover: 1/4NPT 3/4-16UNF
Bolt: 2/1-13UNC
Natural outer diameter: 330mm
Maximum height: 560mm
Minimum height: 180mm
Piston height: 140mm

Benefits of Truck Suspension Air Springs
Improved Comfort: Air springs can provide a smoother and more comfortable ride by absorbing road shocks and vibrations.
Load Support: They help support heavy loads and prevent the vehicle from sagging or bottoming out.
Adjustable Ride Height: Air springs can be adjusted to different ride heights, allowing for better control and handling.
Leveling Capability: They can help level the vehicle when carrying uneven loads, ensuring proper weight distribution.
Reduced Wear and Tear: By absorbing road impacts, air springs can help reduce wear and tear on other suspension components, such as shocks and tires
