2B188168 Double Convoluted Air Suspension G 1/4 Air Hole For Press Equipment
2B188168 Double Convoluted Air Suspension G 1/4 Air Hole For Press Equipment
Product Specifications
| Nut/Blind Nut | |
| Top Cover Plate Screw (Nut) Tooth | 4 pcs X M8X1.25 |
| Screw and Air Inlet Distance of Top Cover Plate | 70mm |
| Bottom Cover Plate Screw (Nut) Tooth | 4 pcs X M8X1.25 |
| Screw Center Distance of Bottom Cover Plate | 70mm |
| Gas Hole / Air inlet / Air Fitting | |
| Gas Hole / Air inlet | G1/4 |
| Cover Plate | |
| Top Cover Plate Diameter | 135mm |
| Bottom Cover Plate Diameter | 135mm |
| Rubber Bellow | |
| Rubber Bellows Natural Diameter | 189mm |
| Rubber Bellow Natural Height | 177mm |
| Compressed Height | 79mm |
| Design Height | 178mm-203mm |
| Maximum Diameter | 218mm |
Cross References Number
| Contitech Number: 603N | Contitech Number: 603 N | Fire-stone Number: W01-358-0142 |
| Fire-stone Number: W01 358 0142 | Fire-stone Number: W013580142 | Fire-stone Flex Number: 26 |
| Phoenix Number: 2B07R | Phoenix Number: 2B07 R | Phoenix Number: 2B 07 R |
| Contitech Number: FD120-17 | Contitech Number: FD 120-17 | Goodyear Number: 2B7-540 |
| Goodyear Number: 2B 7-540 | PIRELLI 26 | AIRKRAFT 114050 |
| BOS-CH 822419042 | DUNLOP 2682 030000 | DUNLOP (FR) SO 8201 |
| FE-STO EB-215-155 | NORGREN PM/31082 (8x2) | PIRELLI T26 84181 |
| TAURUS KF 218 | WEFORMA WBZ 300-E1 | AIRKRAFT 113053 |
Product Applications
- Applications
- Scissor lift
- Hopper vibration and damping
- Mechanical handling stop
- Quick lock device
- Reel tensioning
- Machine isolation
- Direct force
- Impact absorbtion
- Roller tensioning
- Platform lift
- Short stroke mechanical linkage
- Hot foll stamping press
Support and Services
The Suspension Air Springs product technical support and services include:
Expert troubleshooting assistance to diagnose and resolve technical issues
Guidance on proper installation and maintenance procedures
Product documentation, including user manuals and technical specifications
Product training and education for customers and service technicians
Warranty and repair services, including replacement parts and exchange programs
Customer support for urgent technical issues or service needs
