Industrial Air Spring W01-R58-4058 Firestone Air Suspension 1/2 BSP Air Inlet

Price Negotiable
Price: Negotiable
MOQ: 5
Delivery Time: 5-8 Working Days
Brand: GUOMAT
Product Description

Industrial Air Spring W01-R58-4058 Firestone Air Suspension 1/2 BSP Air Inlet





2B10×2 Technical Datas



Rubber Bellows Max. Width 254 mm
Screws Height  27 mm
Minimum Height  70 mm
Top/Bottom Cover Plate Diameter  210 mm
Air Hole/Air Inlet/Gas Hole/Gas Fitting  1/2 BSP
Nut/Blind Nuts  4×M10×1.5
Distance Betweeen Screws  181 mm





2B10×2 Refer Number



Firestone Air Spring

W01-R58-4058, W01 R58 4058, W01R584058

WO1-R58-4058, WO1 R58 4058, WO1R584058

Dunlop Air Spring  SP1538, SP 1538
Contitech Air Spring

FD 210-22 1/2 M10, FD210-22 1/2 M10, FD21022 1/2 M10

FD210 22 1/2 M10, FD 21022 1/2 M10, FD 210 22 1/2 M10

Norgren Air Spring  M 31102(10×2), M31102(10×2), M/31102(10×2)
Samro Air Spring  H2500189, H2500021
Airkraft Air Spring  2B-255 113100, 2B 255 113100, 2B255 113100
Granning Air Spring  15807




2B10×2 Advantages



  1. Long service life
  2. Maintenance-free
  3. Highly operational safety
  4. Frictionless
  5. Lateral misalignment possible
  6. Chemical resistance





GUOMAT Air Spring Applications



  • Pulp and paper industry
  • Lumber mills
  • Lift tables
  • Tooling and machining system
  • Energy production
  • Tooling robotics and automation
  • Component assembly
  • Automotive assembly
  • Medical equipment
  • Conveyor systems
  • Packaging




Company Profile

Guangzhou Guomat Air Spring Co., Ltd. is founded in 2008, the company covers an area of 20000 square meters, registered capital is 10 million yuan, the existing various types of professional and technical personnel is 85 people.The company is located in Guangzhou, about 15min's drive from Baiyun Airport. and our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles' seat, luxurious car and industrial machine field.
W01-R58-4058 Double Convoluted Flange Air Spring with Aluminum Cover Plate

Product Pictures
W01-R58-4058 Double Convoluted Flange Air Spring with Aluminum Cover PlateW01-R58-4058 Double Convoluted Flange Air Spring with Aluminum Cover Plate

W01-R58-4058 Double Convoluted Flange Air Spring with Aluminum Cover Plate
