Product Introduction
The crimped assembly represents a highly durable construction method designed to enhance the air actuator's structural stability and dependability. By improving its capacity to endure challenging operational conditions over extended periods, this design ensures long-lasting performance and resilience. The convoluted bellow, manufactured using premium-grade natural rubber, delivers outstanding dynamic functionality. Its superior flexibility and adaptability enable the actuator to cater to a wide range of industrial and commercial applications, offering exceptional performance across diverse operational environments.
Product Details
| Cover Plate Top Cover Plate Diameter: 231 mm Screw Center Distance of Top Cover Plate: 157.5 mm Bottom Cover Plate Diameter: 231 mm Screw Center Distance of Bottom Cover Plate: 157.5 mm |
| Nuts/Blind Nuts Top Cover Plate Screw (Nut) Tooth: 2×3/8-16UNC Bottom Cover Plate Screw (Nut) Tooth: 2×3/8-16UNC |
| Gas Gole/Gas Fitting/Air Hole/Air Inlet Air Inlet: 1/4 NPTF |
| Rubber Bellow Rubber Bellow Max. Dia: 325 mm Minimum Height: 81 mm Maximum Height: 305 mm Bellows Structure: Double Convoluted Design Height: 160 mm |
Product Technical Data
Force F[kN]
| Pressure P | [bar] | 3 | 4 | 5 | 6 | 7 | 8 |
| Height H [mm] | 300 | 9.8 | 13.1 | 16.7 | 20.3 | 24.0 | 27.7 |
| 260 | 12.5 | 16.7 | 21.0 | 25.4 | 29.9 | 34.5 | |
| 220 | 14.6 | 19.4 | 24.4 | 29.4 | 34.5 | 39.6 | |
| 180 | 16.2 | 21.6 | 27.0 | 32.5 | 38.2 | 43.8 | |
| 140 | 17.6 | 23.4 | 29.3 | 35.2 | 41.3 | 47.2 | |
| 100 | 18.3 | 24.4 | 30.3 | 36.3 | 42.4 | 48.5 |
OEM Numbers
| Fire stone | W01-358-7180 | Fire stone Style | 22 |
| Contitech | FD 330-22 363 | Goodyear | 2B12-425 |
| Goodyear | 2B 12-425 | Goodyear | 578923309 |
| Triangle | 6316/4363 | Airkraft | 115061/3B-356 |
| Vibracoustic | VSP2B22R7180 | EI Ride | 8030190 |
| Leland | SC2075 | Navistar | 1685179C1 |
| Hendrickson | 1VA1816 | Ridewell | 1003587180C |
| SAF Holland | 57007180 | Watson&Chalinl | AS01541G/01881F |
| Peerless | 0550 00001 | - | - |
