Dunlop 6''×3 Triple Convoluted Air Bellow W01-R58-4095 Firestone Air Spring
Dunlop 6''×3 Triple Convoluted Air Bellow W01-R58-4095 Firestone Air Spring
Air Spring Introduction
Air springs have been used in heavy duty vehicle suspension systems for nearly a century, where they have been able to provide usefulness by taking advantage of the compressed air required for vehicle braking systems. Air springs have provided a two-fold advantage over mechanical leaf- or coil-springs. One advantage with air suspension is the extra comfort provided by being able to vary the air pressure inside the spring, which changes the spring rate, and therefore, ride quality. Additionally, because variable control over air pressure adjusts the deck or trailer height, aligning loading docks to the level of the deck is possible when dock plates are unavailable.
Product Standard
| The Top Cover Plate Diameter | 154mm |
| Air Inlet | 1/2 |
| The Top Cover Plate Stud | 4XM10X1.5 |
| The Distance Between the Top Cover Stud | 127mm |
| The Bottom Cover Plate Diameter | 154mm |
| The Bottom Cover Plate Stud | 4XM10X1.5 |
| The Distance Between the Bottom Cover Stud | 127mm |
| Rubber Bellow Diameter | 143mm |
| The Stroke | 105mm-255mm |
3B6×3T Refer NO.
Fire-stone Number: W01-R58-4095
Fire-stone Number: W01R584095
Fire-stone Number: W01 R58 4095
Fire-stone Number: WO1-R58-4095
Fire-stone Number: WO1R584095
Fire-stone Number: WO1 R58 4095
Dunlop Pneuride Number: 6''X3 (Steel)
Dunlop Pneuride Number: 6''x3 (Steel)
Dunlop Springride Number: SP2861
Dunlop Springride Number: SP 2861
Contitech Number: FT76-20DS
Contitech Number: FT 76-20DS
Contitech Number: FT 76-20 DS
Norgren Number: M/31063
Norgren Number: M 31063
Norgren Number: M31063
Parker Number: 9109007
Triple Convoluted Air Springs OEM NO.
| GUOMAT NO. | Firestone | Dunlop Pneuride | Dunlop Springride | Contitech | Norgren | Parker |
| 2 3/4''×3 | 2 3/4''×3 | SP2910 | FT 22-6 DI | 9109010 | ||
| 4 1/2''×3 | W01R584035 | 4 1/2''×3 | SP2895 | FT 44-15 DI | PM/31043 | 9109402 |
| 4 1/2''×3-E | ||||||
| 3B6×3T(AI) | 6''×3(Al) | SP2923 | FT 76-20 DS | PM/31063 | 9109007A | |
| 3B6×3T(Steel) | W01R584095 | 6''×3(Steel) | SP2861 | FT 138-26 DS | M/31063 | 9109007 |
| 3B8×3T | W01R584056 | 8''×3 | SP2863 | FT 138-26 DS | M/31083 | 9109017 |
| 3B10×3T | W01R584059 | 10''×3 | SP1539 | FT 210-32 DS | M/31103 | 9109031 |
| 3B12×3T | W01R584062 | 12''×3 | SP1542 | FT 412-32 DS | M/31123 | 9109051 |
| 3B14 1/2''×3T | W01R584065 | 14 1/2''×3 | SP1558 | FT 614-36 DS | M/31143 | 9109069 |
| 3B16×3T | W01R584068 | 16''×3 | SP2141 | FT 816-40 DS | M/31163 | 9109177 |
