1B12-301 Goodyear Single Convoluted Air Spring Tested FS 330-11 468 Contitech Air Bags
Price:
$49.9-59.9/pc
MOQ:
6pcs
Delivery Time:
2-8 work days
Brand:
GUOMAT
Product Description
1B12-301 Goodyear Single Convoluted Air Spring Tested FS 330-11 468 Contitech Air Bags
Specifications and Detailed Technical Parameters
Type 3 Bead Plate, 2pcs×3/8-16UNC Blind Nuts On 157.5mm Centers, 1/4" NPTF Offset Port, 325mm Max. OD, 68-160mm Working Stroke, 231mm Top and Bottom Cover Plate, With bumper block, Without girdle hoop/Girdle ring
Cross Reference
Firestone W01-358-7009 / W01 358 7009 / W013587009
Contitech FS 330-11 468 / FS330-11 468
Goodyear 1B12-301 / 1B 12-301
Goodyear 578913301 / 578 91 3 301 / 578-91-3-301
Triange 6374 / 4468
| SAF Holland | 90557002 |
| SAF Holland | AR741 |
| Ridewell | 1003587009C |
Force Table
| Assembly Height(in.) | Volume@100PSIG(in3) | Pounds Force | ||||
| @20PSIG | @40PSIG | @60PSIG | @80PSIG | @100PSIG | ||
| 5.0 | 394 | 780 | 1690 | 2640 | 3730 | 4870 |
| 4.0 | 327 | 1300 | 2610 | 4060 | 5500 | 7050 |
| 3.0 | 244 | 1580 | 3280 | 5000 | 6720 | 8440 |
