4884N1P02 Contitech Air Ride Suspension 1R13-118 Goodyear Rubber Air Spring
Product Description
| Firestone | W01-358-9580 |
| 1T17CL-9.5 | |
| Contitech | 4884N1P02 |
| Goodyear | 1R13-118 |
| Airtech | 13192 |
| 39580K | |
| Dayton | 352-9580 |
| E.R.F | 139855-0 |
| Loadguard | SC 2761 |
| Meritor | MLF9025 |
| Triangle | 8434 |
| Hendrickson | C20127 |
| S20127 | |
| MAN | 81.43601-0171 |
Technical Data
Top cover diameter: 262mm
Combo Stud:1/4NPT,3/4-16UNF
Base diameter: 273mm
Natural height: 400mm
Bead Plate Diameter: 264mm
Stud Specifications:3/4-16UNC,1/4 NPTF
Piston Number:9689
Piston Diameter: 273mm
Extended Height: 628mm
Compressed Height: 188mm
Rubber Bellow Diameter: 270mm
Instructions for using rubber air spring
Warning: Do not inflate the air spring when it is not installed. Unless the product is firmly installed in a suitable structure, the maximum pressure is 7 pressures, otherwise there is a risk of product damage or personal injury.
Store
Place the air spring indoors at room temperature in a cool, dry place
Features
The air spring is made of high-quality spring materials. Its good dynamic performance ensures that the air spring is maintenance-free and has a long service life.
Chemical resistance
Wide operating temperature range, from -53 degrees Celsius to 70 degrees Celsius
Oil-resistant compressed air
Resistant to dust
Resistant to alkaline and acidic cleaners
Not sensitive to atmospheric effects
Ozone resistant
Air springs are not resistant to the following substances
Solvent
Hydraulic oil
Grease
