Product Description
The GUOMAT Air springs are highly durable, precisely engineered and cost-effective for use in a wide variety of actuation and vibration isolation applications. With time-tested designs, fabric-reinforced Neoprene or Natural Rubber flex member construction and corrosion-protected end retainers, air springs provide superior quality and performance. We offers a variety of air spring types to meet your actuation or isolation needs. The Single, Double and Triple Convoluted Bellows, Rolling Lobe and Sleeve Types are available in a wide range of sizes, with the End Retainer Style required for your installation.
Product Specifications
| Connection | F1 |
| Maximum Diameter | 210 mm |
| Maximum Height | 145 mm |
| Minimum Height | 45 mm |
| Connecting bolts or holes | 6 N. |
| Connecting bolts or holes | M8×1.25 |
| Thread Air tion Hole | No |
1B Style Industrial Air Bellow
|
Model NO. |
OEM Number |
|
1B4060 |
Contitech : FS 40-6 1/8 M8 Phoenix : SP1B04 Weforma : WBE100-E1 |
|
1B7070 |
Contitech : FS 70-7 Phoenix : SP 1 B 05 Bosch : 822419002 Festo : EB-165-65 Weforma : WBE 200-E1 |
|
1B5010 |
Firestone : W01-358-7731 |
| 1B5010P01 | Firestone : W01-358-7731 |
|
1B1209 |
Firestone : W01-M58-6165 Contitech : FS120-9 Dunlop(FR) : 8"x1 S08101 Bosch : 822419003 Festo : EB-215-80 Norgren : PM/31081,(8x1) Weforma : WBE300-E1 Airtech : 140293 Megatech : 1S12 |
|
1B8X4 |
Firestone : W01-358-7564 Goodyear : 1B8-550 Contitech : FS120-10 |
|
1B8580 |
Firestone : W01-358-7598 Goodyear : 1B8-580 |
|
1B6910 |
Firestone : W01-M58-6374 Contitech : FS200-10 Phoenix : SP1B12 Dunlop(FR) : 9"1/4x110 S091 Bosch : 822419004 Festo : EB-250-85 Norgren : PM/31091(81/4x1) |
|
1B9202 |
Goodyear : 1B9-202 : 578 91 3 201 |
|
1B5330 |
Firestone : W01-358-7008 Contitech : FS330-11474 Goodyear : 1B12-300 Goodyear : 1B12-313 |
|
1B53014 |
Firestone :Style 113 Firestone: W01-358-7103 FleetPride: AS7103 Goodyear: 1B14-350 Goodyear Flex No: 578913351 Taurus :6326 |
Supports and Services
- GUOMAT manufactures efficient, strong, and premium 1H5081 air springs for all your vehicle steering needs. Not only is it efficient in performance, it is also extremely durable, providing long-lasting quality without compromising its effectiveness.
- These 1H5081 air springs are made of high-quality materials, including metal, which ensures maximum stability, durability, and sustainability for demanding use, and is also equipped with the latest features for consistent, optimal performance. These products are certified and tested by regulatory boards to ensure safe use and superior quality.
- When purchasing our products, you can also enjoy a host of after-sales services, including low-cost maintenance, installation guidance, and more. The GUOMAT air springs here are environmentally friendly, with features such as anti-corrosion and anti-rust, and have a longer service life.
FAQ
Q: What is the model number of the Suspension Air Springs?
A: The model number of the Suspension Air Springs is 1H5081
Q: What are the packaging details for the Suspension Air Springs?
A: The Suspension Air Springs are packaged in strong carton boxes or as per the customers' requirements.
Q: How do you guarantee quality?
A: We have testing on aging, hardness, bending, tension, viscosity, rheology, water inspection, bursting, fatigue, etc.
Q: What is your advantage?
A: (1) High quality - Natural rubber.
(2) Fast delivery - Stock sales.
(3) Best service - 24 hours online.
