Product Description

Original Brand: Contitech

Part Number: FD330-22

Part Number: FD 330-22

Part Number: FD330-22 CI

Part Number: FD 330-22 CI

Part Number: FD330-22 CI G1/4

Part Number: FD 330-22 CI G1/4

Part Number: FD330-22 CI G1/4 | 110538

Part Number: FD 330-22 CI G1/4 | 110538

FD330-22 Air Spring Reference Number

Contitech FD 330-22 363

Firestone W01-358-7180/22

Goodyear 2B12-425 / 2B12-311

Goodyear 578-92-3-309

Triangle 6316/4363

Airkraft 115060/3B-356

Contitech FD 330-22 472
Firestone W01-358-7181
Goodyear 2B12-411

Goodyear 578-92-3-309
Triangle 6316/4472

Contitech FD 330-22 500
Firestone W01-358-7344
Goodyear 2B12-034
Triangle 6316/4500

Contitech FD 330-22 313
Firestone W01-358-7400/22
Goodyear 2B12-309/ 2B12-316
Goodyear 578-92-3-309
Triangle 6316/4313

Contitech FD 330-22 337
Firestone W01-358-7401

Goodyear 2B12-320
Goodyear 578-92-3-309
Triangle 6316/4334

Contitech FD 330-22 318

Firestone W01-358-7403/22
Goodyear 2B12-307/2B12-433/2B12-445
Goodyear 578-92-3-309

Contitech FD 330-22 346
Firestone W01-358-7404
Goodyear 2B12-410/2B12-312
Goodyear 578-92-3-309

Triangle 6316/4346

Contitech FD 330-22 364
Firestone W01-358-7405

Goodyear 2B12-313/2B12-459
Goodyear 578-92-3-309
Triangle 6316/4364

Specifications and Detailed Technical Parameters:

Temperature range: -4±50℃ (+70℃/-35±122℉ (+158℉)

Maximum pressure at rest: 8Bar/120psi

Extended height: 305mm
Compressed height: 75mm
Design height: 240mm
Cover diameter: 228mm
Center distance between threaded holes: 157.5mm
Maximum outer diameter of rubber: 325mm

Service Instructions

M8:max.25 Nm

G1/4:max.25 Nm

G1:max.50 Nm

G3/4:max.50 Nm

The Related Picture of FD 330-22
