Product Description
|
Product Description |
Single Convoluted Air Spring |
|
Model No. |
1B200-10 |
|
Warranty |
1 Year Warranty |
|
Material |
Natural Rubber+Steel |
|
Country of Origin |
China |
|
Brand |
GUOMAT/Neutral |
| Color | Black |
| Application | For Industrial Machine |
| Quality | High Quality |
| Delivery Time | About 3-8 working days |
| MOQ | 10 pieces |
| Sample Order | Yes |
GUOMAT 1B200-10 Detailed Technical Data
Failure Testing ≥3 millions
Working Temperature -40℃ bis +70℃
Top Cover Plate Diameter:160mm
Bottom Cover Plate Diameter:160mm
Gas Hole / Air inlet: G3/4
Rubber Bellows Natural Diameter:220mm
The Natural Height: 110mm
Top Cover Plate Screw (Nut) Tooth:2XM8X1.25
Bottom Cover Plate Screw (Nut) Tooth:2XM8X1.25
Screw Center Distance of Top Cover Plate:89mm
Screw Center Distance of Bottom Cover Plate:89mm
Screw And Gas Hole Distance of Top Cover Plate:38mm
1B200-10 Refer to the Following OEM Numbers
Firestone Part Number: W01-M58-6374 / WO1-M58-6374
Firestone Part Number: W01 M58 6374 / WO1 M58 6374
Firestone Part Number: W01M586374 / WO1M586374
Contitech Part Number: FS200-10
Contitech Part Number: FS 200-10
Contitech Part Number: FS200-10 CI
Contitech Part Number: FS 200-10 CI
Phoenix Part Number: SP1B12
Phoenix Part Number: SP 1B12
Phoenix Part Number: SP 1B 12
Dunlop(FR) Part Number: 9''1/4X1 S09101
B-osch Part Number: 822419004
Festo Part Number: EB-250-85
Norgren Part Number: PM/31091 81/4X1
FS200-10 CI Contitech Air Spring
Vibration isolation – dynamic characteristic values
Design height H: recommended 4.33 inch, minimum 3.54 inch
| Pressure P | psi | 40 | 60 | 80 | 100 | 120 | Vol.V(in3) |
| Force (Load) | lbf | 1130 | 1750 | 2420 | 3100 | 3630 | 159 |
| Spring Rate | lbf/in. | 780 | 1210 | 1650 | 2080 | 2510 | |
| Natural Frequency | Hz | 2.6 | 2.6 | 2.6 | 2.6 | 2.6 |
Pneumatic application – static characteristic values
Force F
| Pressure p | psi | 406 | 60 | 80 | 100 | 120 | Vol.V(in3) |
| Height H(in.) | 4.5 | 1040 | 1620 | 2280 | 2910 | 3450 | 160 |
| 4.0 | 1280 | 1960 | 2700 | 3380 | 3990 | 150 | |
| 3.5 | 1460 | 2220 | 3030 | 3800 | 4470 | 130 | |
| 3.0 | 1600 | 2430 | 3290 | 4120 | 4890 | 110 | |
| 2.5 | 1730 | 290 | 3480 | 4390 | 5250 | 86 |
Real Picture-Air Bellow Spring
