FD 530-22 321 Contitech Convoluted Type Rubber Air Bellows W01-358-7136 Firestone Air Spring
Price:
$59.9-69.9/pc
MOQ:
6pcs
Delivery Time:
2-8 work days
Brand:
GUOMAT
Product Description
FD 530-22 321 Contitech Convoluted Type Rubber Air Bellows W01-358-7136 Firestone Air Spring
Product Overview
Industrial-grade rubber air spring designed for vibration isolation and pneumatic applications in industrial platforms and suspension systems.
Product Name: Rubber Air Spring
Model Number: 2B53022
Minimum Order Quantity: 1 PCS
Warranty: 12 Months
Material: Rubber
Packaging: Carton
Technical Specifications
| Path | Minimal Compression | Safe Stretch | Working Stroke |
|---|---|---|---|
| Ø287mm | Ø77mm | Ø310mm | Ø233mm |
- Top Cover Plate Diameter: 287 mm
- Bottom Cover Plate Diameter: 287 mm
- Gas Hole / Air Inlet: G1/4 / G3/4 / G1
- Top Cover Plate Screw (Nut) Tooth: 4XM10X1.5
- Bottom Cover Plate Screw (Nut) Tooth: 2XM10X1.5
- Screw Center Distance of Top Cover Plate: 158.8 mm
- Screw Center Distance of Bottom Cover Plate: 158.8 mm
- Rubber Bellows MAX Diameter: 385 mm
Vibration Isolation - Dynamic Characteristic Values
| Pressure P (bar) | 3 | 4 | 5 | 6 | 7 | 8 | Vol V(I) |
|---|---|---|---|---|---|---|---|
| Force(Load) (KN) | 15.2 | 20.7 | 25.8 | 31.5 | 36.8 | 42 | 18.7 |
| Spring Rate (N/cm) | 2225 | 2860 | 3495 | 4130 | 4765 | 5400 | - |
| Natural Frequency f0 (Hz) | 1.9 | 1.8 | 1.8 | 1.8 | 1.8 | 1.7 | - |
Pneumatic Application - Static Characteristic Values
| Pressure P (bar) | 3 | 4 | 5 | 6 | 7 | 8 | Vol V(I) |
|---|---|---|---|---|---|---|---|
| Height H(mm) 260 | 14.1 | 19.3 | 24.1 | 29.5 | 34.5 | 39.4 | 19.5 |
| Height H(mm) 220 | 18.2 | 24.4 | 30.5 | 37 | 43.2 | 49.1 | 16.5 |
| Height H(mm) 180 | 21 | 28.2 | 35.3 | 42.6 | 49.7 | 56.8 | 13.6 |
| Height H(mm) 140 | 23.1 | 31 | 38.7 | 46.5 | 54.3 | 61.9 | 10.5 |
| Height H(mm) 100 | 24.4 | 32.3 | 40.4 | 48.7 | 56.8 | 64.7 | 7.2 |
Compatible Part Numbers
Firestone: W01-358-7136
Contitech: FD 530-22 321
Goodyear: 2B14-356
Goodyear: 2B14-453
Goodyear: 578-92-3-353
Goodyear: 578-92-3-351
Triangle: 6329
Triangle: 4321
Brake&Wheel: M3503
Ridewell: 1003587136C
Dayton: 3547136
Leland: Sc2014
Navistar: 554798C1
Hendrickson Auxillary: QW12AX
Hendrickson Trailer: S1080/C1
Tuthill Technology: 1626
Watson&Chalin: AS004
V-olvo: 3130489
SAF Holland: 57007136
