Double Pcs Steel Girdle Ring Industrial Air Springs / Air Bags 3 Convolution
Price:
Negotiable
MOQ:
1 pc
Delivery Time:
2-8 work days
Brand:
GUOMAT
Product Description
YOKOHAMA S-350-3 Rubber Air Spring 350-3 With Double Pcs Steel Girdle Ring For Friction Press
S-350 items Detailed Parameter Table:
| GUOMAT NO. | Reference No. | Hight H(mm) | Commonly Maximum Stroke(mm) | The Largest Diameter When Compressed(mm) | ||
| Design High(mm) | Maximum High(mm) | Minimum Height(mm) | ||||
| F-350-1 | S-350-1 | 72 | 117 | 40 | ±30 | 450 |
| F-350-2 | S-350-2 | 102 | 160 | 55 | ±42 | 410 |
| F-350-3 | S-350-3 | 160 | 250 | 85 | ±65 | 410 |
| F-350-4 | S-350-4 | 218 | 336 | 118 | ±85 | 410 |
| GUOMAT NO. | Reference No. | Standard Height,Internal Pressure 0.49 M pa When The General Value | Using Maximum Internal Pressure (M pa) | Internal Pressure (M pa) | ||||
| Effective Area (Cm2) | Volume(L) | Load (K n) | Dynamic Spring Parameters (N/Min) | Vibration Frequency (Hz) | ||||
| F-350-1 | S-350-1 | 960 | 6.9 | 47.1 | 1520 | 2.8 | 0.69 | 2.9-3.9 |
| F-350-2 | S-350-2 | 960 | 9.5 | 47.1 | 1040 | 2.3 | 0.88 | 3.9-4.9 |
| F-350-3 | S-350-3 | 960 | 15 | 47.1 | 647 | 1.8 | 0.88 | 3.9-4.9 |
| F-350-4 | S-350-4 | 960 | 21 | 47.1 | 471 | 1.6 | 0.88 | 3.9-4.9 |
GUOMAT Has Punch Press Air Spring Cushion /Air Shock Absorber Part NO. Below:
| GUOMAT Part NO. | Japan YOKOHAMA Reference No. | Japan YOKOHAMA Reference No. | GUOMAT Part NO. | Japan YOKOHAMA Reference No. | Japan YOKOHAMA Reference No. |
| F-600-1 | S-600-1R | S-600-1 | F-240-4 | S-240-4R | S-240-4 |
| F-600-2 | S-600-2R | S-600-2 | F-240-3 | S-240-3R | S-240-3 |
| F-600-3 | S-600-3R | S-600-3 | F-240-2 | S-240-2R | S-240-2 |
| F-600-4 | S-600-4R | S-600-4 | F-240-1 | S-240-1R | S-240-1 |
| F-600-5 | S-600-5R | S-600-5 | F-220-4 | S-220-4R | S-220-4 |
| F-550-2 | S-550-2R | S-550-2 | F-220-3 | S-220-3R | S-220-3 |
| F-550-3 | S-550-3R | S-550-3 | F-220-2 | S-220-2R | S-220-2 |
| F-500-2 | S-500-2R | S-500-2 | F-200-2 | S-200-2R | S-200-2 |
| F-500-3 | S-500-3R | S-500-3 | F-200-3 | S-200-3R | S-200-3 |
| F-500-4 | S-500-4R | S-500-4 | F-200-4 | S-200-4R | S-200-4 |
| F-500-5 | S-500-5R | S-500-5 | F-160-1 | S-160-1R | S-160-1 |
| F-450-1 | S-450-1R | S-450-1 | F-160-2 | S-160-2R | S-160-2 |
| F-450-2 | S-450-2R | S-450-2 | F-160-3 | S-160-3R | S-160-3 |
| F-450-3 | S-450-3R | S-450-3 | F-160-4 | S-160-4R | S-160-4 |
| F-450-4 | S-450-4R | S-450-4 | F-120-4 | S-120-4R | S-120-4 |
| F-450-5 | S-450-5R | S-450-5 | F-120-3 | S-120-3R | S-120-3 |
| F-400-2 | S-400-2R | S-400-2 | F-120-2 | S-120-2R | S-120-2 |
| F-400-3 | S-400-3R | S-400-3 | F-100-4 | S-100-4R | S-100-4 |
| F-400-4 | S-400-4R | S-400-4 | F-90-3 | S-90-3R | S-90-3 |
| F-400-5 | S-400-5R | S-400-5 | F-90-2 | S-90-2R | S-90-2 |
| F-350-1 | S-350-1R | S-350-1 | F-90-1 | S-90-1R | S-90-1 |
| F-350-2 | S-350-2R | S-350-2 | F-300-1 | S-300-1R | S-300-1 |
| F-350-3 | S-350-3R | S-350-3 | F-300-2 | S-300-2R | S-300-2 |
| F-350-4 | S-350-4R | S-350-4 | F-300-3 | S-300-3R | S-300-3 |
| F-300-4 | S-300-4R | S-300-4 |
