Super Cushion Goodyear Air Spring 2B9-204 Firestone W013586900 For Suspensions 630173
Goodyear Super Cushion Air Spring 2B9-204 Firestone W013586900 For Suspensions 630173
Specifications and Technical Data of 2B6900
Firestone Part Number:W01-358-6900 / W013586900 / W01 358 6900
Compressed Height: 3.12
Top Plate Number:3079
Top Cover Plate Diameter: 6.31 inches / 160mm
Bottom Cover Plate Diameter: 6.31 inches / 160mm
Screw Center Distance : 89 mm
Distance Gas Hole Between Nut 38 mm
Top Cover Plate Screw (Nut) Tooth : 2pcsX 3/8-16UNC
Bottom Cover Plate Screw (Nut) Tooth : 2pcsX 3/8-16UNC
Rubber Bellows MAX Diameter: 251 mm
Rubber Bellows Natural Diameter 224 mm
The Working Stroke : MAX 260 mm to MIN 75 mm
Gas Hole / Air inlet : 3/4 NPT
Firestone Bellows Number:20
Goodyear Part Number:2B9-204 / 2B9204 / 2B9 204
Goodyear Bellows Number:578-92-3-202 / 578923202 / 578 92 3 202
GUOMAT NO. 2B6900 OEM Original Equipment Manufacturer:
| Reference | OEM |
| Firestone | W01-358-6900 |
| Contitech | FD 200-19 319 |
| Contitech | 161017 |
| Goodyear | 2B8-157 |
| Goodyear | 2B9-204 |
| Goodyear | 2B9-207 |
| Goodyear | 2B9-216 |
| Goodyear | 578923202 |
| Dina | A1812719 |
| MASA | 227138412 |
| Ridewell | 1003586900C |
| Suspensions | 630173 |
| Watson&Chalin | AS-0156G |
