Japan Industry Rubber Air Spring For Punching Clamping Device 0.69 Mpa
Japan Industry YOKOHAMA S-450-2R Air Spring for Punching Clamping Device 450-2
Net Weight:7 KG
Gross Weight:8 KG
Package Size:120 mm*500mm*500mm
This item Detailed Parameter Table:
| GUOMAT NO. | Reference No. | Hight H(mm) | Commonly Maximum Stroke(mm) | The Largest Diameter When Compressed(mm) | ||
| Design High(mm) | Maximum High(mm) | Minimum Height(mm) | ||||
| F-400-2 | S-400-2 | 102 | 167 | 57 | ±45 | 460 |
| GUOMAT NO. | Reference No. | Standard Height,Internal Pressure 0.49 M pa When The General Value | Using Maximum Internal Pressure (M pa) | Internal Pressure (M pa) | ||||
| Effective Area (Cm2) | Volume(L) | Load (K n) | Dynamic Spring Parameters (N/Min) | Vibration Frequency (Hz) | ||||
| F-400-2 | S-400-2 | 1260 | 11.9 | 61.6 | 1344 | 2.3 | 0.69 | 2.9-3.9 |
Lots of industria equipment use this air spring:
- Improve the actuator of the hospital diagnostic table
- Reciprocating shaft seal
- Shock absorber test system
- Underwater actuator for door control
- Seat suspension
- Industrial washing machine
- Protect Polaris and Atlas rockets in storage, ground
- Transit transit
- Leather mechanical equipment air spring,
- Coordinate measuring tables and machinery
- Detecting the platform air spring air spring,
- Replace the steel spring for better vibration isolation.
- Mechanical coupling
- Power source for laminated plywood presses
- Granite plate locator
- Pallet lift
- Conveyor terminal block
S-450-2R Yokohama Air Spring fits for the following Punch press:
- High-speed punching machine parts
- Lead frame press
- EI piece precision punching machine
- Button punching high speed punch
- Motor stator punching machine
- Connector high-speed punch press
- Terminal precision punching machine
- The LED bracket punch
- Net punching basin horn
- Fin high-speed punch press
GUOMAT air spring production of the air spring has the following advantages:
1, product quality, Thailand import natural rubber, the core technology in Germany
2, With the same price on the market, GUOMAT optimal quality. With the same quality of products, GUOMAT has lowest price.
3, cars, trucks, buses and industrial air spring has production, fully meet the customers' different requirements.
4, GUOMAT spell price, not only do the brand.
5, more than 10 years of production technology, products cover all over the world.
6, have dealers around the world, the first response to all customer requirements.
