Contitech Air Spring FD 200-25 427 Triangle Air Shock Suspension 4427 Leland Sc2125

Applications of GUOMAT 2B6945 AIR SPRING airbag

The drive axle GUOMAT 2B6945 AIR SPRING greatly improves the driving and handling performance of the tractor, thereby improving the comfort and safety of the driver. GUOMAT 2B6945 AIR SPRING reduces the maintenance of the tractor, prolongs the wear of the tires, and increases the depreciation price of the car.GUOMAT 2B6945 AIR SPRING hardly needs too much maintenance, and the service life of GUOMAT 2B6945 AIR SPRING may be more than twice that of steel springs.

GUOMAT NO. 2B6945 Specifications:

Top hole/stud: 3Bottom hole/stud: 2Top cover: 6.4 inches / 160 mmDiameter of the bottom cover: 6.4 inches / 160 mmFolded height: 3.8 inches / 96 mmTop cover screw center distance: 3.5 inches / 89 mmScrew center distance of the bottom cover: 3.5 inches / 89 mmNatural diameter of rubber bellows: 232.5 mmWorking stroke: maximum 309 mm to minimum 96 mm / maximum 12.2 inches to minimum 3.8 inchesMaximum height: 12.2 inches / 309 mmMinimum height: 3.8 inches / 96 mmCompressed height: 8.3 inches / 213 mmNatural rubber bellows: 9.2 inches / 235 mm

GUOMAT NO. 2B6945 Cross others OEM

GUOMAT Part NO. 2B6945

Conti Tech: FD200-25427 /

Conti Tech: FD200 25427

Conti Tech:FD200-25 427

Goodyear Trimmed: 2B9253

Firestone W01-358-6945 / 20-2

Firestone W01 358 6945 / 20-2

Firestone W013586945  / 20-2

Firestone W01-358-6945

Firestone W01 358 6945

Firestone W013586945

Firestone:20-2

Goodyear 2B9-253

Goodyear Flexmember: 578-92-3-206 /

Goodyear Flexmember:578923206 /

Goodyear Flexmember:578 92 3 206

Triangle Spring: 4427 /

Triangle Spring:6332

Firestone: 6945

Conti Tech: 64550

Ridewell: 1003586945C

Batco: 10-96945

UCF / Impex: AB-2B9-253

T.W. Distribution: AB6945

Dallas Spring: AS6945

Midland / Haldex: CS209253

Euclid/Meritor Aftermarket: E-FS6945

Euclid/Meritor Aftermarket: FS6945

Leland: SC2125

Watson&Chalin : AS0119F / AS01451G

Details Technical data at the below photo

Vibration isolation - dynamic characteristic values

Pneumatic application - static characteristic values Force F [kN]
