Goodyear Air Spring 2B14-354 Bellows 578923353 Refer to Firestone W013587145

2B14-354 Goodyear Cross OEM

FIRESTONE 7145,W013587145,Conti 64548,FD530-22374,DAYTON 354-7145,INTL / NAVISTAR 554796C1,LOAD GUARD SC2016,Mac-k truck TRUCK 57QL239,RIDEWELL 1003587145C,S-4540-C,TRIANGLE 4374,VOL-VO 35203-0005,35203 -3204

Firestone Part No.:W01-358-7145

Firestone Part No.:W01 358 7145

Firestone Part No.:W013587145

Conti Tech Part No.:FD 530-22 CI 1/4 NPT

Conti Tech Part No.:FD530-22 CI 1/4 NPT

Goodyear Part No.: 2B14-350 ;

Goodyear Part No.: 2B14 350;

Goodyear Part No.: 2B14350

Goodyear Part No.: 2B14-354;

Goodyear Part No.: 2B14 354;

Goodyear Part No.: 2B14354

Roof hole/stud: 5
Base plate hole/stud: 4
Top plate diameter: 11.3
Base plate diameter: 11.3
Collapse height: 3.5
Flexible members: 578-92-3-353
piston:
Piston type:-
Goodyear Trim: 2B14354
Crossover
Triangle spring: 4374
Firestone: 7145
Kangdi Technology: 64548
Reedwell: 1003587145C
batco: 10-97145
Goodyear Airlines: 2B14-350
VOL-VO/White/Car: 35203-0005
VOL-VO/White/Car: 35203-3204
Navistar / IHC: 554796C1
Mike: 57QL239
UCF / Impex: AB-2B14-354
Dallas Spring: AS7145
Midland / Haldex: CS214354
Euclid / Meritor Aftermarket: E-FS7145
ContiTech: FD530-22374
Euclid / Meritor Aftermarket: FS7145
BWP: M-3505
Hendrickson auxiliary equipment: S-13038
Reedwell: S4540C
Leland: SC2016

2B14-354 Goodyear product parameters

❶Nut/blind nut
Top plate screw (nut) teeth: 4 x 3 / 8-16UNC
Screw center distance of the top cover plate: 159 mm
Screw (nut) teeth of the bottom cover plate: 4 x 3 / 8-16UNC
The screw center distance of the bottom cover plate: 159 mm

❷Air hole/air inlet/air fitting
Air hole/air inlet: 1/4NPT
Center distance between nut and air inlet: 79.5 mm

❸cover
Top plate diameter (width): 289 mm
Diameter (width) of the bottom cover plate: 289 mm

Bell rubber bellows
Maximum diameter of rubber bellows: 406 mm
Compressed height: 104 mm / 4.1 inches
Maximum height: 391 mm
Working stroke: 287mm

❺Bumper block/bumper block
With bumper

❻Belt loop/Belt loop
Attached belt: a belt
