GTX5020R GEN II 150401 88.57/119.96mm 13+0 blades point milling turbo billet compressor wheel for 851285-5020S

1. MODEL:GTX5020R GEN II forward

2.GTX5020R GEN II 150401 88.57/119.96mm 13+0 blades point milling turbo billet/milling/aluminum 2618 compressor wheel for 851285-5020S

3.Size:

Nose diameter:21.20mm

inducer:88.57mm

Exduder:119.96mm

Tapered tip exducer:128.40mm

Tip height:6.30mm

Superback:8.55mm

Overall height:69.40mm

bore size :9.50mm

bore type:Threaded-M9x1.5-LHT

Trailing Angle:70 degree

Cutback:7.4mm

Blades height:48.40mm

Splitter height:0.00mm

Sp height angle:0.00

13+0 blades

Forward rotation

Tapered tip angle:39 degree

It is custom size ,please check carefully before buying.

Application:

851285-5020S

4.High quality and competitive price.

5.if you want more details, please send email to me.

We can produce as your requirement.the minimun order is 5pcs

The more models we also have.
