B03G reverse 9+0 blades 62.00/82.00mm Turbo milling/aluminum 2618/Billet compressor wheel

Price Negotiable
Price: Negotiable
MOQ: 1PC
Delivery Time: 3-7 days
Brand: NO
Product Description

1.  MODEL:B03G reverse
2.B03G reverse 9+0 blades 62.00/82.00mm Turbo Billet/milling/aluminum 2618 compressor wheel
3.Size:
Nose diameter:14.00mm
Inducer:62.00mm
exducer:82.00mm
Tapered tip exducer:84.40mm
Tip height:6.95mm
Superback:4.00mm
  bore size :5.61mm
bore type:through
Overall height:41.00mm
Cutback:6.7mm
Trailing Angle:35 degree
Sp height angle:0.0
Splitter height:0.00mm
Blade height:35.00mm
9+0 blades  reverse rotation
It is custom size ,please check carefully before buying.
Tapered tip Angle:11.6 degree
4.High quality and competitive price.
5.if you want more details, please send email to me.

All the compressor wheels have been balanced.
