GT15-25 436131-0002/436131-0016 38.62/52.19mm 7+7 blades performance Turbo milling/aluminum 2618/billet compressor wheel

1. MODEL:GT15-25 forward

2. GT15-25 436131-0002/436131-0016 38.62/52.19mm 7+7 blades high performance Turbo Billet/milling/aluminum 2618 compressor wheel for

452204-0001, 452204-0003, 452204-0004, 452204-0005, 452204-0007 / 454061-0006, 454061-0007, 454061-0008, 454061-0009, 454061-0010, 454061-0011, 454061-0012, 454061-0014 / 454135-0001, 454135-0002, 454135-0006 / 701196-0001, 701196-0002, 701196-0006, 701196-0007 / 704594-0001, 704594-0004, 704594-0009 / 705954-0004, 705954-0009

3.Size:

Nose Diameter:10.42mm

inducer:38.62mm

Exducer:52.19mm

Tapered tip exducer:56.39mm

Tip height:4.64mm

Superback:2.39mm

Overall height:26.07mm

Bore size:5.08mm

bore type:through

Trailing angle:60 degree

Cutback:6.0mm

SP height angle:0.00

Splitter height:11.00mm

Blade height:21.81mm

7+7 blades

forward rotation

Tapered tip angle:30 degree

it is for OE compressor housing

Application:

452204-0001, 452204-0003, 452204-0004, 452204-0005, 452204-0007 / 454061-0006, 454061-0007, 454061-0008, 454061-0009, 454061-0010, 454061-0011, 454061-0012, 454061-0014 / 454135-0001, 454135-0002, 454135-0006 / 701196-0001, 701196-0002, 701196-0006, 701196-0007 / 704594-0001, 704594-0004, 704594-0009 / 705954-0004, 705954-0009

4.High quality and competitive price.

5.Any questions please send email to me.

All the billet compressor wheels have been balanced.

We have more size ,if you want ,please don't hesitate to contact me.
