HX60 4040285 80.00/113.01mm 7+7 blades high performance turbo milling/Aluminum 2618/billet compressor wheel for 4047148

Price Negotiable
Price: DISCUSS
MOQ: 1PC
Delivery Time: 3-7 DAYS
Brand: NO
Product Description

1. MODEL:HX60

2. HX60 4040285 80.00/113.01mm 7+7 blades high performance turbo billet/milling/Aluminum 2618 compressor wheel for 4047148/4038499/4042879

3.Size:

Nose Diameter:20.83mm

inducer:80.00mm

Exducer:113.01mm

Tapered tip exducer:120.41mm

Tip height:7.41mm

Superback:9.27mm

Overall height:55.99mm

Bore size:11.12mm

Trailing angle:50

Cutback:1.0

Splitter height:29.85mm

SP height angle:-10.00

Blades height:44.47mm

7+7 BLADES

forward rotation

Tapered tip angle:30 degree

It is for OE compressor housing

4.High quality and competitive price.

5.Any questions please send email to me.We have many size.

All the compressor wheel have been balanced.
