RHF5 reverse 52.56/68.001mm 5+5 blades high performance turbo aluminum 2618/milling/billet compressor wheel

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 3-7 days after payment
Brand: no
Product Description



1. MODEL:RHF5 REVERSE

2.RHF5 reverse 52.56/68.01mm 5+5 blades high performance aluminum 2618/Billet/milling compressor wheel
3.Size:

Nose diameter:11.60mm

Inducer:52.56mm

exducer:68.01mm

Tapered tip exducer:73.05mm

Tip height :5.36mm

superback:1.53mm

Overall height:28.70mm

Bore size:5.10mm

Trailing Angle:60

Cutback:3.0

SP height angle:-1.20

Blade height:25.20mm

Splitter height:15.90mm

5+5 blades

reverse rotation

Tapered tip angle:30 degree

It is custom size ,please check carefully before buying

4.High quality and competitive price.

5.Any questions please send email to me.

All the compressor wheel have been balanced.

We can produce as your requirement.
