TD04H 41.94/56.00mm 11+0 blades high performance turbocharger milling/aluminum 2618/billet compressor wheel ​

1.Model:TD04H Forward

2.TD04H 41.94/56.00mm 11+0 blades high performance turbocharger milling/aluminum 2618/billet compressor wheel ​

3.SIZE:

Nose diameter:10.96mm

inducer:41.94mm

Exducer:56.00mm

Tapered tip exducer:60.88mm

Tip height:5.23mm

Superback:1.90mm

Overall height:25.81mm

bore size :5.00mm

bore type:through

Trailing Angle:60

Cutback:0.0

SP height Agnle:0.00

Splitter Height:0.00mm

Blades height:21.98mm

11+0 blades

FORWARD rotation

Tapered tip Angle:30 degree

It is custom size ,please check carefully before buying.

4.Good quality and competitive price ​

5.Please send email to me or talk to me on online ,if you want to know more details.

All the compressor wheels have been balanced.

We can produce as your requirement.the minimum order is 5pcs
