Interface-Echo Mode:
(I-E or Standard Mode)


1.50mm – 20.0mm
(0.059in – 0.787 in)



Echo-Echo Mode:
(E-E or High Precision Mode)


0.15mm – 10.0mm
(0.006in – 0.394in)


±0.005mm or 0.0002 inch (if thickness < 3mm)



±0.05mm or 0.002 inch (if thickness < 20mm)



mm : 0.1 / 0.01 / 0.001



inch : 0.01 / 0.001 / 0.0001



1000 to 9999 m/sec (0.0394 – 0.3936 inch/ms)



4Hz in normal mode, up to 25Hz



500 test values



One point or Two Point



42×57mm LCD size with EI backlight and adjustable contrast, font size up to 13.75mm (0.54 inch)



2 pcs. 1.5v AA size batteries



About 200 hours (with backlight off)



Auto power off if idle for 4 minutes



-10 °C to +50 °C



2.9 W x 5.9 H x 1.26 D inches (73 W x 149 H x 32 D mm).



200g



Main unit with Calibration block (4.00 mm)



Precision Probe (D11R) with Replaceable Delay Tip



Coupling Paste



Operation Manual



Consumer-Type 2 AA Type Alkaline Battery (3 Volt)



Carrying Case
