Yellow color PVC coating Holland wire mesh fence 30mmx30 mm Hole opening ​ in 1.2 meter height

Price Negotiable
Price: Price based on quantity
MOQ: 1 piece
Delivery Time: 5-8 working days
Brand: XKh
Product Description

         Yellow color PVC coating Holland wire mesh fence 30mmx30 mm Hole opening  in 1.2 meter height







1.INTRODUCTION :



Material : Q195Low carbon steel wire

Wire Diameter: 2.0mm,2.2 mm ,2.3mm ,2.5mm, 2.8mm , 3mm ,3.2mm,-3.5mm(after coating )

Wire surface treatment : Galvanized core wire + PVC(plastic powder coating )

Hole Aperture :

Squre hole : 1/2inch (1.3cm)x1/2 inch (1.5cm) ,  1.5cmx1.5cm ,2.5cm x2.5cm , 3cmx3cm , 5cmx5cm ,6 cmx6cm ,10cmx10cm  ,etc

Rectangle hole :3cmx6cm, 5cmx10cm , 7.5cmx10cm ,etc

Hole shape : with wave or without wave

Width of roll : 60cm , 90cm , 100cm , 150cm , 180cm , 200cm

.Height : 10m,18m,25m, 30m(or customerized )

 Distance Between The Two Fence Posts: 3m

 Distance Between The Two Inclined Posts: 30m

 Plastic Color: Dark Green/Grass Green/White /Yellow /Red





SO FAR WE ARE THE ONLY MANUFACTURE - OWN STOCK OF YELLOW COLOR ( SHAPE -WITHOUT WAVE )

Whole Year -we have stock below size & we accept customerized size .

Holland Wire Fence Mesh/WELDED WIRE MESH (Yellow color) PVC coating
Hole Aperture Height Length Weight Stock
cm mm inch meter meter KG/roll Y/N
3x3 30x30 1.2x1.2 1.2 18 9 YES
3x3 30x30 1.2x1.2 1.5 18 12.5 YES
3x6 30x60 1.2x2.4 1.2 30 15 YES
3x6 30x60 1.2x2.4 1.5 30 18 YES
6x6 60x60 2.4x2.4 1.2 30 12 YES
6x6 60x60 2.4x2.4 1.2 30 16 YES
6x6 60x60 2.4x2.4 1.2 30 27 YES
6x6 60x60 2.4x2.4 1.2 30 20 YES
6x6 60x60 2.4x2.4 1.5 30 15/15.5 YES
6x6 60x60 2.4x2.4 1.5 30 17 YES
6x6 60x60 2.4x2.4 1.5 30 20 YES
6x6 60x60 2.4x2.4 1.5 30 24.5 YES
6x6 60x60 2.4x2.4 1.5 30 33 YES
6x6 60x60 2.4x2.4 1.8 30 19 YES
6x6 60x60 2.4x2.4 1.8 30 22 YES
6x6 60x60 2.4x2.4 1.8 30 28.5 YES



Note :Same hole ,same height x length , but different diameter ,then different weight



3x3 cm show :





6X6cm Show :







2. Prepare installation :

When we install it as fence , we will choose the post -peach type and round type post , but the most suitable type is swallow tail post :

Post Color : Green ,Yellow , Red ... etc





                              001 First step : prepare associate parts : clips , anti -rain cap & pliers :





                             002 Second step : Fixed two types of post in different of ground condition



Embedded post -

(dig hole , put post and fill full of soil , if want more strong , then we can for long-term use,   it will be better if pour with concrete or lime. normally it is 30cm deepth , but if above 1.8m - need to bear more pressure , we suggest 50cm  embedded deepth ,)





Post with base plate -





Inclined Post -( every 30meter )



One or double





                          003 Third step : FixHolland /welded Mesh

3. Application :

    used widely in industry, agriculture, building, transportation, mine, field, lawn, cultivation etc professions'guard  and decoration





4.Our Yellow color holland wire mesh show :









5.we also do other color of holland wire mesh :



  GRASS GRREN , DARK GREEN ( LARGE STOCK ) :







DARK COLOR :









 RED COLOR :





BLUE COLOR :





   WELCOME YOUR VALUED INQUIRY :

   Mobile /whatsapp/wechat :008618730291422

   E-mail : alisawiremesh@hotmail.com

   Person : Alisa Zhou



   We Have larges stock for green and yellow color in 6x6cm in 1m,1.2m,1.5m,1.8m,2m

   And also Your customerized specification is our pleasure also .
