Glareless COB LED Lens Match Normal White Bridgelux LED 30W 6500K
Glare-Less COB Led Lens For 30w 6500K Normal White Bridgelux Led
Quick Detail:
1. Dimension: Dia 67mm Height 20mm
2. Beam Angle: 120degree, Anti-glare
3. Match Led: 10-100w LEDs
4. Materials : Borosilicate glass3.3
5. Accessories: Stainless Steel holder, Silicone gasket
6. Chips Package size < 53mm
7. Application: Flashing light, Led Spot Light, Led high bay light, Flood light
Specifications:
| Product Name |
50w COB Led Lens With 6000K Pure White Bridgelux Led 45mil Chip |
| Model No | SOE-HB67-120A |
| Main parts | Optical glass Lens+silicone gasket+metal holder+Multichip LED+Driver MeanWell |
| Lens Material | Borosilicate Glass3.3 |
| MOQ | 1 pc |
| Lens size | 67mm, height 20mm |
| Sample | 3 days |
| Delivery | 7-9 days |
Material Details:
Optical Grade High Borosilicate Glass 3.3
Light transmittance (2mm): 92%
High hardness
Never get yellow comparing with PMMA an PC material
Refractive index : 1.474
Thermal expansivity : (3.3 ± 0.1)×10-6/K
Heat resistant : working at -50~550 °C
Density (20 °C) : 2.23 gcm-1
COB Led Glass Lens Drawing:
Related COB Led Glass lens:
| Model No. | Lens angle | Lens Dimensions | Match Led |
|
SOE-HB67-90A
|
90° | D67mm*H24mm | 10-100W |
|
SOE-HB67-120A
|
120° | D67mm*H20mm | 10-100W |
|
SOE-HB78-60A
|
60° | D78mm*H40mm | 50-200W |
|
SOE-HB78-90A
|
90° | D78mm*H35mm | 50-200W |
|
SOE-HB78-120A
|
120° | D78mm*H26mm | 50-200W |
|
SOE-HB114A
|
120° | D100mm*H33mm | 50-200W |
COB Led lens Applications:
It is used for High bay and low bay lighting, Flood Light, Spot Light, Applicate for Industrial factory, warehouse, stadium, hypermarket, supermarket and other indoor environments.
