Digital Vickers Hardness Tester QHVT-10Z With Touch Screen And Vickers Operation System
MOQ:
1 Set
Delivery Time:
10 Working Days
Brand:
iqualitrol
Product Description
Digital Vickers Hardness Tester with Touch Screen and Vickers Software System
Download Technical Data:
Main Features:
1. Machine body apply aluminum alloy die-casting process, strong and stable;
2. Motor direct drive type vertical loading test force, the force value is more stable;
3. Special material lifting shaft, more stable structural design;
4. The turret is faster and the testing efficiency is higher.
Technical Specifications:
| Model | QHVT-10Z | QHVT-50Z | |
| Test force | kgf | 0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf | 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf, 20kgf, 30kgf, 50kgf |
| N | 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N | 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N, 196N, 294N, 490N | |
| Test Modes | HV/HK | ||
| Vickers Range | 1HV~2967HV | ||
| Vickers Resolution | 0.1HV | ||
| Loading Control | Auto (Loading/dwell/unloading) | ||
| Turret | Auto Turret | ||
| Data Output | Built-in Printer, RS232 | ||
| Display | Touch Screen, support data saving | ||
Hardness | HK, HRA, HRBW, HRC, HRD, HREW, HRFW, | ||
| Eyepiece | 10x digital eyepiece | ||
| Objectives | 10x,40x | 10x,20x | |
| Total Magnification | 100x,400x | 100x,200x | |
| FOV | 10x:800μm, 40x:200μm | 10x:800μm, 20x:400μm | |
| Length Resolution | 10x:0.25μm, | 10x:0.25μm, | |
| Dwell Time | 0~60s | ||
| Illumination | LED Light | ||
| X-Y Anvil | Size: 120×120mm; Travel: 25×25mm; | ||
| Max Height of Specimen | 175mm | ||
| Throat | 140mm | ||
| Power supply | AC220V,50Hz | ||
| Executive Standards | ISO 6507, ASTM E92, JIS Z2244, GB/T 4340.2 | ||
| Dimension | 495×575×670mm | ||
| Weight | Net 35kg, Packing weight 55kg | ||
