Single Disc Economical Grinding and Polishing Machine with Stepless Speed 100-1400rpm
Single Disc Economical Grinding and Polishing Machine with Stepless Speed 100-1400rpm
Download Technical Data:
Brief Introduction:
HMP-1 is an economical grinding and polishing machine which integrates pre-grinding, grinding and polishing.
By using single chip microcomputer technology to control through thin film switch panel, grinding and throwing disc using DC brushless motor to drive, V belt transmission, with smooth rotation, low noise, long life, safe and reliable characteristics;
The running speed is adjustable according to the needs of users, adapt to different needs; with cooling device, samples can be cooled during grinding to prevent the sample overheating damage metallographic structure, factory, scientific research units and colleges and universities laboratory metallographic sample preparation equipment ideal.
Technical Specifications:
| Product model | HMP-1 |
| Number of grinding discs | 1 |
| Grinding disc diameter | 203 mm (Optional 230mm, 254mm) |
| Grinding speed | 100-1400rpm, quick setting 300, 600, 900, 1400rpm |
| Grinding wheel steering | clockwise or counterclockwise |
| Motor power | 1100w |
| Power supply | AC220V/50Hz/1Ph |
| Shape dimensions | 475*660*330 mm |
