Furnace Refractory Lining | Hex Metal Armouring | 253MA | 16ga thickness | 60mm hexagonal mesh | HESLY China Exporter

Hexmetal is a hexagonal cellular mesh grating specifically designed for reinforcing both linings and flooring. It acts as a surface framework to hold cement or refractory in position, and relieves stress in the lining’s upper crust, which prevents spalling and cracking. As a result of hex metal’s strength and unique design, abrasion and corrosion are retarded and refractory life is significantly extended. Even hot gaseous substances cannot erode the refractory because they are reflected away from the surface by the metal cellular grid.

Applications of Hexmetal

Hexagonal mesh or Hexmesh as it often referred to is a honey comb pattern of steel bars used to retain refractories in anti-abrasive and anti-corrosive thin wall linings used in the oil, petrochemical, metallurgical, chemical, and cement industries.

The HESLY™ range of hexagonal mesh comprises many different styles with or without protruding lances to meet the specifications set by process engineering companies and refractory suppliers.

HESLY™ hexagonal mesh can be supplied in flat panels manufactured from 19 tor 25mm thick plates and supplied in panels 2000x1000mm or rolled and tailored for welding to the walls of cyclones, reactors, furnaces and vessels.

Standard Bonding Hole Pattern	Lance Pattern

Typical Service Temperature

Hexmetal Common Specification Sheet

HEX-MESH PHOTOS

Welded Hexmetal	Welded hexmetal
Double Clench Hex Steel	Double Clench Hexsteel
Offset Lances Hexmesh	Offset Lances Hexmetal
Hex Metal Sheet	Hex Metal Sheet
