100G QSFP28 LR4 Optical Transceiver Single Mode Fiber Module SMF LC Connector 1310nm 10km
Price:
Negotiable
MOQ:
1pcs
Delivery Time:
Negotiable
Brand:
HILINK
Product Description
SMF LC Connector 1310nm 10km 100G QSFP28 LR4
100G QSFP28 LR4
The QSFP28 Transceiver module is designed for 103Gigabit Ethernet links over 10km single mode fiber. It is compliant with IEEE 802.3ba 100GBASE-LR4. Digital diagnostics functions are available via an I2C interface, as specified by the QSFP+ MSA.
Features:
>Supports 103Gbps
>Single 3.3V Power Supply and Power dissipation <3.5W
>Up to 10km over SMF
>Commercial case temperature range: 0℃ to 70℃
>Four 25Gbps DML LAN-WDM channels on transmitter side
>PIN and TIA array on the receiver side
>4x25G electrical interface
>Duplex LC receptacles
>I2C interface with integrated Digital Diagnostic Monitoring
>RoHS 6 compliant
Applications:
100GBASE-LR4
Infiniband QDR/DDR/SDR
100G Datacom connections
>Supports 103Gbps
>Single 3.3V Power Supply and Power dissipation <3.5W
>Up to 10km over SMF
>Commercial case temperature range: 0℃ to 70℃
>Four 25Gbps DML LAN-WDM channels on transmitter side
>PIN and TIA array on the receiver side
>4x25G electrical interface
>Duplex LC receptacles
>I2C interface with integrated Digital Diagnostic Monitoring
>RoHS 6 compliant
Applications:
100GBASE-LR4
Infiniband QDR/DDR/SDR
100G Datacom connections
This product is a 100Gb/s transceiver module designed for optical communication applications compliant
with 100GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 input channels of 25Gb/s
electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel
for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s
optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of
electrical data.
Hilink QSFP28 100G Series
| Part Number | Data Rate | Distance | Wavelength | Output Power | Sensitivity | Remark |
| HQ28-SR-M85-X1D | 100Gbps | MM 100m (OM4) |
850nm | -8.4 ~ +2.4dBm | -10.3dBm | QSFP28-100G-SR4 |
| HQ28-LR-L13-10D | 100Gbps | SM 10km | 1310nm | -4.3 ~ +4.5dBm | -10.6dBm | QSFP28-100G-LR4 |
| HQ28-LR-L13-10C1 | 100Gbps | SM 10km | 1310nm | -4.3 ~ +4.5dBm | -10.6dBm | QSFP28 100G-LR4-Ethernet |
| HQ28-ER-L13-40D | 100Gbps | SM 40km | 1310nm | -2.9 ~ +4.5dBm | -16.9dBm | QSFP28 100G-ER4 |
| HQ28-K7-L13-xxx | 100Gbps | SM 2km | 1310nm | -6.5 ~ +2.5dBm | -11.5dBm | QSFP28 100G-CWDM4 |
Parameter
The 25g~100G Series
| 25G SFP28 SR4 | 25Gbps 850nm SFP28 transceiver 100M |
| QSFP-40G-SR4 | QSFP-SR4, MMF, 850nm, 150M, MPO |
| QSFP-40G-CSR4 | QSFP+, MMF, 850nm, 300M (OM3) - MPO |
| QSFP-40G-LR4 | QSFP-LR4, SMF, 1270nm~1330nm,15KM LC |
| QSFP-40G-PSM-IR4 | QSFP+-IR4,SMF ,1310NM 2KM MPO |
| 40G QSFP+ PSM 10KM | QSFP+-LR4,SMF ,1310NM 10KM MPO |
| 100G QSFP28 SR4 | 100GBASE-SR4 QSFP28 |
| QSFP28 CWDM4 2KM | 100G QSFP28 CWDM4 2KM 1271~1331 |
| QSFP28 CWDM4 500M | 100G QSFP28 CWDM4 500 1271~1331 |
| QSFP28 PSM4 1310nm 2km | QSFP28 PSM4 1310nm 2km MPO SMF |
| 25G SFP28 AOC 1M | 25Gbps 850nm Multimode SFP28 AOC 1~100M |
| 25G SFP28 DAC SFF-8402 | 25G SFP28 to SFP28 DAC 1m 3m 5meter |
| 40G QSFP+ AOC 1M | QSFP-AOC Active 40Gbase 1~100meter |
| 40G QSFP+ DAC 1M | QSFP SFF8436 Passive Cable 1~5M |
| 100G QSFP28 TO QSFP28 DAC | 1M 2M 3M 5M SFF-8665 100G QSFP28 Passive |
| 100G QSFP28-SR4 AOC 1M | 100GBASE-SR4 QSFP28 AOC Fiber |
