Multimode Fiber Cable WDM MPO Male To MPO Male Patch Cord 24 Core OM4 10M
Multimode Fiber cable MPO male to MPO male patch cord 24 core OM4 10M
2.MPO connector and fiber optic cable processing can produce various forms of MPO jumper.
3.MPO optical fiber connector includes optical fiber, sheath, coupling component, metal ring, PIN PIN, dust cap, etc.
4.MPO jumpers are widely used in high-density integrated optical fiber line environments.
5.The total length of MPO jumper or branch length and other requirements are at the customer's option.
1.IEC61754-7 Compliant;Telcordia GR-1435-CORE
compliant.
2.Push -Pull locking type.
3.Ferrules are available for SM Standard,SM Low Loss;
MM Standard,MM Low Loss.
4.Cable are available for Jacket ribbon,Bare ribbon,
Round mini Cable.
5.High Return Loss;Low Insertion Loss.
6.High precision guide pins for exact alignment.
PRODUCT TYPE:
| Code | Male(With pin),Female(Without pin) |
| Ferrule | SM Standard,SM Low Loss;MM Standard,MM Low Loss. |
| Ferrule Holes | 4,8,12,24 |
| Housing Color | Green(for SM), Beige(for MM),Yellow(for SM Low loss),Aqua( for OM3 50/125 ) |
| Polishing | PC,APC |
| Cable | Jacket ribbon,Bare ribbon,3.0mm Mini cable(250um 12F/24F), |
