Custom Schedule 120 Stainless Steel Seamless Pipe AISI 304L SUS304
Custom Schedule 120 Stainless Steel Seamless Pipe AISI 304L SUS304
Specifications:
0.03 maximum carbon content of 316 stainless steel tube can be used for welding can not be annealed and the need for maximum corrosion resistance.
|
Technical Parameter for Seamless Pipe |
Tensile Strength |
520-530Mpa |
|
Yield Strength 0.2% |
205 - 225 |
|
|
Elongation % |
35 - 38 |
|
|
Corrosion test |
ACCEPTABLE |
|
|
Flaring |
ACCEPTABLE |
|
|
Hydraulic |
ACCEPTABLE |
|
|
Eddy Current |
ACCEPTABLE |
|
|
PMI |
ACCRPTABLE |
|
|
Surface |
Acid wash, annealing |
|
|
Ends |
Beveled and Caps |
|
|
Packing |
Woven bags |
About 2ton for each bundle |
|
Dimension |
OD Size |
6mm - 630mm |
|
Thickness |
0.5mm - 25mm |
|
|
Length |
5 - 5.8m, 6m,double random length |
|
|
Certificate |
ISO/SGS/BV/Lloyd/ABS/CCS/RINA/GL/DNV |
|
Description:
|
Chemical |
C |
Si |
Mn |
Cr |
Ni |
S |
P |
Mo |
Ti |
|
% |
≤0.08 |
≤1.00 |
≤2.00 |
16.00～18.00 |
10.0～14.0 |
≤0.030 |
≤0.045 |
2.0~3.0 |
5(C+N)≤0.70 |
Weight calculation formula of 316Ti stainless steel management theory: (outside diameter -wall thickness) x wall thickness x 0.02513=KG/M
Applications:
Used in industries as chemical engineering, petroleum, medicine, food, energy, nuclear power, aerospace,
environmental protection, boiler, gas, war industry, machinery, ship building and so on.
Competitive Advantage:
Our factory is near to raw material market and high-speed way, the producing cost is low.
Our factory have long history for producing stainless steel seamless pipe,both producing and testing
machine is advanced and perfect.
Our factory was certificated by BV/ISO/LR/RINA/CCS/GL/ABS/DNV, which can improve the quality.
We participated in many famous projects with our pipes.
Hydrostatic Pressure Test Machine
