PDJ Pneumatic Hose Connector Branch Run Tee Push In One-Touch Air Quick Fittings High Quality Sanmin
PDJ Pneumatic Hose Connector Branch Run Tee Push In One-Touch Air Quick Fittings High Quality Sanmin
Specification
| 1 | Brass with good nice nickel plated. |
| 2 | BSPT thread (British Standard Taper Pipe Thread). |
| 3 | Each and every pcs was tested at 10kgs/cm2. |
| 4 | Thread with PTFE coating which can seal directly without any other seal material. |
|
Fluid
|
Air , Vacuum
|
|
Operating Pressure
|
0-1.0MPa
|
|
Negative Pressure
|
-100KPa (10Torr)
|
|
Max Pressure
|
1.5MPa
|
|
Operating Temperature
|
5 ~ 60 ℃
|
|
Applicable Tube
|
Polyurethane and Nylon
|
Why choose us
1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
| Focus Point | High Temperature Environment Countermeasures | Extreme Cold Environment Countermeasures |
| Seals | Fluororubber, PTFE | Low-temperature nitrile, silicone rubber, polyurethane |
| Lubrication | High-temperature synthetic grease (low volatility) | Low-temperature grease (low pour point, low viscosity) |
| Air Supply Treatment | Strengthen cooling, efficient water removal | Ultra-low dew point drying (refrigeration + adsorption type), heat tracing |
| Metal Components | Reserve expansion clearance | Select materials with low-temperature toughness, prevent leakage due to cold shrinkage |
| Control Components | High heat-resistant grade coils, heat dissipation, low power consumption | Install insulation boxes, local heating, prevent cold condensation |
| Installation | Keep away from heat sources, add heat insulation plates | Avoid exposure to wind and snow, wrap with thermal insulation materials |
|
Rotating elbow: allow the air pipe to rotate after connection to increase flexibility. but locking mechanism is provided to ensure safe and reliable connection. mechanical manufacturing and other fields. of electronic equipment. Such joint usually needs to comply with specific standards, such as VDA standards. |
