MHE Smart Automatic Industrial Portable Charger 24v 40A 50A With Long Life

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: 15 days after order confirmation

Brand: LAKER

Product Description

High-Frequency Industrial Battery Charger for MHE

Model Name: ESCH24V40A-O ESCH24V50A-O

Product Parameters

Model	ESCH24V40A-O	ESCH24V50A-O
Dimensions (mm)	Long * wide * high:349227189 (mm)
Output maximum current (A)	40	50
Maximum power point (W)	1200	1500
Input voltage (VAC)	220V±15% (Customizable)
Output voltage (VDC)	Lead-acid batter:31V; VRLA:29.4V;(customizable)
Applicable battery voltage	24V lead-acid battery pack, (Customizable, Lithium battery optional)
Maximum efficiency	93%
Output voltage regulation precision	±1%
Output current accuracy	±1%
Working temperature	-30℃～-45℃
Classes of seismic measure	SAEJ1378
Cooling mode	Air blast cooling
Over temperature protection	75℃±5
Input under-voltage protection (VAC)	Under-voltage point 90V
Output over-voltage protection (VDC)	31V±1
Output over-current protection (A)	>110%*Maximum charge current
Output short circuit protection	When the output is short circuited, charger shutdown, and automatic recovery after short-circuit solved.
Battery reverse protection	Charger shutdown and alarm when the wire is connected reversely, it will automatically resume after wiring correctly.

Product Specification

Charger integrates active power factor correction (PFC), can achieve zero pollution of the power grid and avoid the impact of large current grid;
The input voltage range is very wide, AC185V-AC264V, suitable for any region’s voltage level of the world, have a great convenience for the power grid fluctuations and vehicle exports.
The efficiency is very high, can reach more than 93%, the traditional charger can only reach about 80%.
The intelligent temperature compensation function of the charging process can avoid the damage caused by the overcharge or under the charge of the battery, and the service life of the battery can be prolonged.
Do the internal charger seismic processing, seismic grade up to SAEJ1378, fully meet the electric vehicle-using standard.
Use the LLC resonance technology, whole charging process working under soft-switching condition, with less heating of the whole machine.

Product Characteristics

Single Chip Microcomputer (SCM) according to the lead-acid batteries tolerance current capacity, life curve, gas analysis point and other information to complete the full charge of the whole process;
With the environmental temperature compensation function, to ensure that the temperature of the weather conditions, can automatically resist over-charge and under-charge;
With pulse charging function, the battery is filled with the premise of ensuring the best life of the battery；
After three paint processing and dustproof design, the reliability of the operation is improved;
With digital display function, can display online charging current, voltage, charging time;

Packaging & Delivery

Packaging Details:

Cartons, Pallets

Delivery Detail:

In 7 to 15 days against the order confirmation and deposit.
