Pharmaceutical Plastic Bottle Production Machine , Blow Injection Molding Machine
Pharmaceutical bottles making machine ,Injection blow moldng machine with PP,LDPE/HDPE
Product introduction
Our company professionally manufactures Injection Blow Molding machine and mould series.
It is a kind of three station-one step hollow molding machine.Products volumes are from 5ML to 600ML, suitable for general material.PE, PP, PS, ABS, SAN, PETG, PCTG, TPU, etc, widely applied to many packing fields, such as Pharmaceuties, Food,Drink,Cosmetic,etc.
Product parameters
| Name | Unit | FG30 | FG45 | FG60 | FG80 |
| Screw diameter | mm | 40 | 45 | 50/55 | 60 |
| L/D Ratio | 22:1 | 22:1 | 22:1 | 22:1 | |
| Injection Capacity | 9 | 176 | 260 | 314 | 415 |
| Heating power | KW | 7.5 | 10 | 10.8 | 12 |
| Heating section | 3+N | 3+N | 4+N | 4+N | |
| Injection mould clamping force | KN | 400 | 600 | 800 | 1000 |
| The injection mold opening stroke | mm | 140 | 140 | 140 | 150 |
| Mould clamping force | KN | 60 | 100 | 120 | 150 |
| Blow mold opening stroke | mm | 140 | 140 | 140 | 150 |
| Injection stroke | mm | 160 | 160 | 160 | 160 |
| Mold Size | mm | 480*340 | 600*390 | 800*400 | 1000*460 |
| Min. Thickness of Mold | mm | 180 | 240 | 280 | 280 |
| Main motor power | KW | 11 | 18.5 | 22 | 30 |
| Reject Stroke | mm | 210 | 230 | 230 | 230 |
| Dry Cycle Time | s | 3.5 | 4 | 4 | 4 |
| Total power | KW | 20 | 30 | 40 | 45 |
| Operating power | % | 52-70 | 52-70 | 52-70 | 52-70 |
| System pressure | Map | 14 | 14 | 14 | 14 |
| Compressed air pressure | MPa | 0.7-1.2 | 0.7-1.2 | 0.7-1.2 | 0.7-1.2 |
| Cooling water pressure | MPa | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 |
| Product maximum diameter | mm | 120 | 120 | 120 | 120 |
| Product maximum length | mm | 200 | 220 | 220 | 220 |
| Product volume | ml | 3-800 | 3-800 | 3-1000 | 3-1000 |
| Dimensions | M | 3*1.3*1.7 | 3.5*1.4*1.8 | 4*1.6*2 | 4.5*1.8*2 |
| Equipment weight | Ton | 3.5 | 5 |
Product operation
● Adopt Electro-Hydrauliec Hybrid Servo System Can Save 40% power than usual.
● Adopt three-cylinder to lock the mold with the replenishing valve,can make the high and short cycle products.
● Apply the double vertical pole and single horizontal beam to make enough rotation space,longer bottles,make the mold installation easy and simple.
● Adopt electrical rotation system for client option, rotation speed and precision can be controlling.
