Auto Rotary 3 In 1 PET Water Bottle Filling Equipment 3000BPH-25000BPH
Still Mineral Water Rotary Filling Machine/Rinsing-Filling-Sealing 3 in 1 Water Filling Machine
1. Capacity(B/H):5000
2. Filling heads:14-12-5
3. Bottle type(ml):250-2500
Drinking Water Filling Machine
The Manufacturer sales MIC Machinery automatic 3-in-1 mineral water plastic bottle production filling machine line is mainly used in the beverage filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic.
| Technical parameters | 8/8/3 | 18-18-6 | 24-24-8 | 32-32-10 |
| Production capacity (500ml)(B/H) | 3000 | 6000 | 10000 | 14000 |
| Bottle washing station | 2 | 2.5 | 5 | 6 |
| Drying station | 2 | 3.5 | 6 | 10 |
| PET bottle size (mm) | D=60~97mm | |||
| H=150~320mm | ||||
| Capping torque (N.m) | 0.6~2.8 | 0.6~2.8 | 0.6~2.8 | 0.6~2.8 |
| Installed capacity (Kw) | 2.38 | 2.38 | 4.18 | 4.18 |
| Compressed Air consumption(0.6Mpa)Nm3/min | 0.5 | 0.5 | 0.6 | 0.8 |
| Washing bottles water consumption(0.2-0.25Mpa)m3/h | 1.5 | 1.5 | 1.5~2 | 1.5~2 |
| Dimension(L*W*H)(mm) | 2300×2000×2850 | 2500×2000×2850 | 2800×2300×2850 | 4150×2560×2850 |
| Weight(t) | 4 | 4.5 | 6 | 7 |
Characteristic:
1. intelligent contact screen, human design, easy operation.
2. Imported filling valve, avoiding drop leaking, accurate filling quantity.
3. Program logic controller(PLC), easy for changing size or modifying parameters.
4. Pneumatic elements are all imported, stability and reliability.
5. Accurate liquid sensing, automatically adding liquid, ordinary pressure flow passage parameters
6. Solely and specially-designed whole lifting device, easy governing to meet the needs of all kindsof container packing
7. Photo-electric sensing and pneumatic linking control, automatic protection for shortage of bottle.
8. Pneumatic executive control valve, high efficiency and safety. Each flow passage can be separately governed and cleaned.
9. Close positioning design, easy governing, suitable for packing of all sizes of bottles.
10. The whole machine is designed according to requirements of buyer's.
