Plastic Baler Machine ,PET Bottle Balers ,Plastic Baling Machine
Usage :
Specialized in recycling and compressing the loose materials like plastic films ,PET bottles, plastic pallets ,waste paper ,grass ,fiber ,used clothes ,cartons ,cardboards trims ,scrap ,etc .
Features
● Servo System With low Noise ,low consumption which is reduce half power of electrical charge,Smoothly running without any shake
● Fully automatic compress and baling, suitable for large amount material places, after baling it is easy store and reduce the transportation cost.
● Unique automatic strapping device, speed quickly ,frame simple, motion steady. Failure rate is low and easy to clean maintenance.
● Can choose transmission line materials and air-blower Feeding. Suitable to waste cardboard recycling companies, plastic, fabric large garbage disposal sites and so on.
● Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient
● Automatically detect and show the errors of the machine which improve the machine inspection efficiency
● International standard electric circuit layout, graphic operation instruction and detailed parts marks makes the operation been more easily understanding and improves the maintenance efficiency
| Item | Name | parameter |
|
mainframe parameter |
Bale size | 1100mm(W)×1100mm(H)×～1800mm(L) |
| Material type | Scrap Kraft paper, Newspaper, Cardboard ,Soft Film, Plastic, | |
| Material density | 650～750Kg/m3(Moistures 12-18%) | |
| Feed opening size | 2400mm×1100mm | |
| Main motor power | 37KW×2sets+15KW | |
| Main cylinder | YG300/230-2900 | |
| Main cylinder force | 200T | |
| Capacity | 25-30Ton/hour | |
| Max. system working force | 30.5MPa | |
| Mainframe weight(T) | About 30 tons | |
| Oil tank | 2m3 | |
| Mainframe size | About 11×4.3×5.8M(L×W×H) | |
| Tie wire line | 4 line φ3.0-3.2mm3 iron wire | |
| Pressure time | ≤30S/ (go and back for empty load) | |
| Chain conveyor technology | Model | NK-III |
| Conveyor weight | About 7 tons | |
| Conveyor size | 2000*14000MM | |
| terra hole size | 7.303M(L)×3.3M(W)×1.2M(deep) | |
| Conveyor motor | 7.5KW | |
| Cool tower | Cool tower motor | 0.75KW(water Pump)+0.25(Fan) |
