High Efficiency Spring Type Cone Crusher Industrial Cone Crushing Machine
Mining Industry Limestone Spring Cone crusher description:
1.stone Spring Cone crusher is widely used in industries of metallurgy, architecture, road construction, chemical industry, phosphate.
2.stone Spring Cone crusher is the preferred choice for secondary crushing equipment which is used for hard and medium mineral rock such as iron ore, copper ore, limestone, quartz, granite, basalt and dolerite.
Mining Industry Limestone Spring Cone crusher Features:
1,Strong crushing force; High efficiency; High crushing capacity;
2,Low operation and maintenance cost, easy to adjust;
3,As spare parts selection and structural design is reasonable, the lifespan will be longer;
4,Reducing downtime;
5,Different types of crushing chambers to satisfy different customers’ requirement.
Mining Industry Limestone Spring Cone crusher Specification
| Type |
Dia. of Cone (mm) |
Adjusting Range of Discharge Opening (mm) |
Max Feed Size (mm) |
Capacity (t/h) | Motor Power (kw) | Weight (t) |
Overall Dimension (mm) |
| PYB-600 | 600 | 12-25 | 65 | 15-25 | 30 | 5.5 | 1740×1225×1940 |
| PYD-600 | 3-13 | 36 | 5-23 | 30 | 5.5 | 1740×1225×1940 | |
| PYB-900 | 900 | 15-50 | 115 | 50-90 | 55 | 10.18 | 1990×1640×2380 |
| PYZ-900 | 5-20 | 60 | 20-65 | 55 | 10.19 | 1990×1640×2380 | |
| PYD-900 | 3-13 | 40 | 15-50 | 55 | 10.27 | 1990×1640×2380 | |
| PYB-1200 | 1200 | 20-50 | 145 | 110-200 | 110 | 24.7 | 2805×2300×2980 |
| PYZ-1200 | 8-26 | 100 | 50-150 | 110 | 25 | 2805×2300×2980 | |
| PYD-1200 | 3-15 | 50 | 18-105 | 110 | 25.6 | 2805×2300×2980 | |
| PYB-1750 | 1750 | 25-60 | 215 | 280-480 | 155-160 | 50.6 | 3610×2950×4185 |
| PYZ-1750 | 10-30 | 185 | 115-320 | 155-160 | 51 | 3610×2950×4185 | |
| PYD-1750 | 5-15 | 85 | 75-230 | 155-160 | 50.5 | 3610×2950×4185 | |
| PYB-2200 | 2200 | 30-60 | 300 | 590-1000 | 260-280 | 84 | 4790×3430×5080 |
| PYZ-2200 | 10-30 | 235 | 200-580 | 260-280 | 85 | 4790×3430×5080 | |
| PYD-2200 | 5-16 | 110 | 120-370 | 260-280 | 85 | 4790×3430×4852 |
