Stone Crushing Mini Vibrating Machinery Small Vibrating Screen For Mining Industry
small vibrating screen description:
The circular vibrating screen moves on a circular motion. It is a multi-layer and high efficiency vibrating screen.It has the advantages of stable structure, strong exciting force, high efficiency, little noise pollution, handy maintenance and safety.
The vibrating screen is mainly made up of the screening box, exciter, suspension (or supporting) device and motor, etc. The motor drives the exciter axis through the triangle belt. With the effect of the centrifugal inertia force caused by the imbalance of weight, the screening box of the round vibrating screen starts vibrating. By changing the eccentric weight, different amplitudes can be achieved.
small vibrating screen Features:
Simple structure; it is easy to replace the screen;
High screening efficiency, low energy consumption;
High wear resistance, low noise
The circular vibrating screen moves on a circular motion. It is a multi-layer and high efficiency vibrating screen. It has the advantages of stable structure, strong exciting force, high efficiency, little noise pollution, handy maintenance and safety; circular vibrating screen has been widely used in mine, construction, transportation, energy and chemical industry.
Technical Superiority of Circular Vibrating Screen
small vibrating screen specifications:
| Model | Screen Size (mm) |
Screen layers | Mesh Size (mm) |
Max Feeding Size (mm) |
Capacity (t/h) |
Motor (kw) |
Vibrational Frequency (r/min) |
Double amplitude (mm) |
| 2YK1237 | 3700*1200 | 2 | 3-80 | 100 | 10-80 | 11 | 750-950 | 5-9 |
| 3YK1237 | 3700*1200 | 3 | 3-80 | 100 | 10-80 | 11 | 750-950 | 5-9 |
| 2YK1548 | 4800*1500 | 2 | 3-80 | 100 | 30-200 | 15 | 750-950 | 5-9 |
| 3YK1548 | 4800*1500 | 3 | 3-80 | 100 | 30-200 | 15 | 750-950 | 5-9 |
| 2YK1848 | 4800*1800 | 2 | 3-80 | 100 | 50-250 | 18.5 | 750-950 | 5-9 |
| 3YK1848 | 4800*1800 | 3 | 3-80 | 100 | 50-250 | 18.5 | 750-950 | 5-9 |
| 2YK1860 | 6000*1800 | 2 | 3-80 | 100 | 60-300 | 22 | 750-950 | 5-9 |
| 3YK1860 | 6000*1800 | 3 | 3-80 | 100 | 60-300 | 22 | 750-950 | 5-9 |
| 4YK1860 | 6000*1800 | 4 | 3-80 | 100 | 60-300 | 30 | 750-950 | 5-9 |
| 2YK2160 | 6000*2100 | 2 | 3-80 | 100 | 80-400 | 22 | 700-900 | 5-9 |
| 3YK2160 | 6000*2100 | 3 | 3-80 | 100 | 80-400 | 30 | 700-900 | 5-9 |
| 4YK2160 | 6000*2100 | 4 | 3-80 | 100 | 80-400 | 30 | 700-900 | 5-9 |
| 2YK2460 | 6000*2400 | 2 | 5-80 | 100 | 100-500 | 30 | 700-900 | 5-9 |
| 3YK2460 | 6000*2400 | 3 | 5-80 | 100 | 100-500 | 37 | 700-900 | 5-9 |
| 4YK2460 | 6000*2400 | 4 | 5-80 | 100 | 100-500 | 37 | 700-900 | 5-9 |
Note: the processing capacity is described on the basis of data about processing mid-hard materials and the bulk density of crushed materials is 1.6t /m3
